Belt Tensioner Units

These belt tensioner units are commonly used in conveyor and industrial belt drives, to maintain correct belt tension over time.

168 products

Loading filters…

Belt Tensioner Units

What is a belt tensioner unit?

A belt tensioner unit is a sliding bearing unit used to adjust the tension of a conveyor belt. It holds a self-aligning insert bearing in a cast iron slide block, which fits inside a separate tensioner housing. Turning an adjusting screw moves the bearing unit along the housing, which moves the shaft and pulley to tighten or slacken the belt. Once the tension is right, the screw is locked to hold the unit in place.

A standard belt tensioner set-up is made up of:

  • A cast iron tensioner bearing unit, which slides inside the housing
  • A self-aligning insert bearing, fitted in the tensioner unit and locked to the shaft
  • A tensioner housing, which is either bolted down or welded to the conveyor frame
  • An adjusting screw, which sets the position of the bearing unit and can be locked once adjusted.

The tensioner unit and housing are sold separately.

  • The bearing unit carries the shaft and does the moving, while the housing provides the guide it slides in.
  • Different bearing units, with different bore sizes and insert types, fit the same housing, so one housing style can be used across a range of shaft sizes.

The insert bearing can be removed from the tensioner unit and replaced when it wears, and a grease nipple allows it to be relubricated.

Why are belt tensioner units essential?

Conveyor belts stretch in service, and a belt that is too slack will slip on the drive pulley, run off line, and wear quickly. A belt that is too tight overloads the bearings, shafts, and splices. A belt tensioner unit gives a simple, built-in way to set the tension when the conveyor is installed and to adjust it as the belt stretches over time.

Because the bearing unit slides in its own housing, adjustment is smooth and controlled. Fitting a tensioner on each side of the tail pulley lets the pulley be moved squarely, or one side be adjusted slightly to correct a belt that tracks to one side.

Typical applications include:

  • Conveyor tail pulleys
  • Belt conveyors in quarrying and aggregates
  • Agricultural and grain handling conveyors
  • Recycling and waste handling equipment
  • Food processing and packaging conveyors
  • Mining and bulk handling equipment
  • General materials handling

The main types of belt tensioner units

  • Tensioner units with full width grub screw inserts - The standard design. The insert bearing is locked to the shaft with two grub screws, which suits most conveyors and drives that run in either direction.
  • Tensioner units with eccentric collar inserts (EC) - These use a flat back insert locked to the shaft with an eccentric collar and grub screw. The collar grips the shaft without marking it, and suits drives that run in one direction.
  • Bolt-down tensioner housings with feet - These housings have feet with bolt holes, so they can be bolted to the conveyor frame. They are quick to fit and easy to remove.
  • Weld-on tensioner housings - These housings have no feet and are welded directly to the conveyor frame, for a strong, permanent fixing.
  • Metric and inch bore units - Tensioner units are available for both metric and inch shafts.

How to choose the right belt tensioner unit?

  • Shaft size - Choose a tensioner unit with an insert bore that matches the pulley shaft, and check whether the shaft is metric or inch.
  • Insert type - Choose a grub screw insert for general use and drives that run either way, or an eccentric collar insert where the shaft must not be marked and the drive runs in one direction.
  • Housing type - Choose a bolt-down housing with feet if you want to be able to remove it, or a weld-on housing for a permanent fixing.
  • Adjustment travel - Check the housing gives enough travel to tension the belt and take up stretch over its life.
  • Load and speed - Check the load ratings and maximum speed of the tensioner unit suit the belt tension and pulley speed.

Essential references and specialised ranges

How the numbering works:

Belt tensioner units are usually listed by series and bore size. In the RHP BT range, for example:

BT = belt tensioner bearing unit

The number after BT is the bore size, in inches or mm:

BT7/8 = 7/8 inch bore

BT1 = 1 inch bore

BT35 = 35mm bore

Tensioner housings have their own references:

BTHF = bolt-down tensioner housing with feet

BTH = weld-on tensioner housing without feet

The bearing unit and housing are ordered separately, and each housing takes all BT units in the range.

Suffixes:

EC = eccentric collar locking insert (for example, BT35EC)

No suffix = full width insert with grub screw locking

Suffix codes vary between manufacturers, so check the supplier’s catalogue for the exact meaning.

FAQ - All you need to know about belt tensioner units

What is the difference between a belt tensioner unit and a take-up unit?

Both are used to adjust belt or chain tension by moving a shaft. A take-up unit is a single housing that slides in a frame. A belt tensioner unit is a bearing unit that slides inside a separate tensioner housing, which is bolted or welded to the conveyor.

Do I need to buy the housing separately?

Yes. The tensioner bearing unit and the tensioner housing are sold separately. Choose a bearing unit for your shaft size, and a bolt-down or weld-on housing to suit your conveyor frame.

How do I adjust a belt tensioner unit?

Release the lock on the adjusting screw, then turn the screw to move the bearing unit along the housing until the belt is at the right tension. Adjust both sides of the pulley by the same amount to keep it square, then lock the adjusting screws.

Do belt tensioner units need lubrication?

Yes. The insert bearing has a grease nipple for relubrication. Conveyors often run in dusty conditions, so regular regreasing helps keep dirt out of the bearing. Keep the adjusting screw clean and lightly greased so it turns freely.

How do I fit a belt tensioner unit?

Bolt or weld the tensioner housing to the conveyor frame, then slide the bearing unit into the housing and fit the adjusting screw. Slide the pulley shaft through the insert bearing, set the belt tension, and lock the insert to the shaft. Recheck the tension after the conveyor has run for a short time.

How do I identify a belt tensioner unit I need to replace?

The reference is usually marked on the tensioner unit and the insert bearing. If it cannot be read, measure the shaft diameter and the overall length, width, and height of the unit. Also check the insert locking type and whether the housing is bolted down or welded on.

What are the signs that a belt tensioner unit needs replacing?

Look out for:

  • Grinding, squealing, or rumbling from the bearing
  • The belt slipping or losing tension more often than usual
  • Increased vibration from the pulley
  • The bearing unit running hot
  • Play in the shaft
  • The unit sticking in the housing, or a damaged adjusting screw
  • Grease and dirt pushing out of the seals
