Tension Arms

These tension arms are commonly used in conveyor drives, to hold idler pulleys and sprockets in position for correct tension.

6 products

Loading filters…

Tension Arms

What is a tension arm?

A tension arm, also called a chain and belt tensioner, is a spring-loaded arm that holds a tension sprocket or tension roller against a chain or belt to keep it at the correct tension. Many tension arms use a rubber spring element inside the housing. When the arm is rotated and locked into position, the rubber element is twisted and pushes the arm back towards the chain or belt with a steady force. As the chain or belt stretches over time, the arm moves automatically to take up the slack, keeping the drive tight without the need for constant manual adjustment.

Tension arms are compact, simple to fit, and work with both roller chains and belts. A tension sprocket is fitted to the arm for chain drives, while a tension roller is fitted for belt drives. The tension arms in this range are made in sizes such as SE11, SE15, SE18, and SE27, with larger sizes providing greater tensioning force for bigger drives.

A typical tension arm has:

  • Housing - the body of the tensioner, which is bolted to the machine frame
  • Rubber spring element - inside the housing, providing the tensioning force and absorbing shock and vibration
  • Arm - extends from the housing and carries the sprocket or roller
  • Mounting hole or slot - at the end of the arm, used to fix the tension sprocket or tension roller
  • Mounting bolt - fixes the housing to the machine frame or bracket

Tension arms are usually described by:

  • Size - such as SE11, SE15, SE18, or SE27, which relates to the tensioning force and the size of drive it suits
  • Tensioning force - the force the arm applies to the chain or belt
  • Arm length - the distance from the centre of the housing to the sprocket or roller mounting
  • Thread size - the size of the bolt used to fit the sprocket or roller

Key features:

  • Automatic tensioning - keeps chains and belts tight as they stretch and wear
  • Constant tension - maintains a steady, even force on the drive
  • Absorbs shock and vibration - the rubber element cushions sudden loads and reduces chain whip and belt flapping
  • Maintenance-free - no lubrication or adjustment needed in normal use
  • Compact design - fits easily onto machine frames and brackets
  • Chain and belt compatible - works with tension sprockets for chains and tension rollers for belts
  • Range of sizes - to suit small drives through to larger industrial drives

In simple terms, a tension arm is a spring-loaded arm that keeps a chain or belt tight automatically, using a sprocket or roller pressed against the drive.

Why are tension arms essential?

Tension arms are essential because chains and belts stretch as they wear. Without regular adjustment, they become slack, causing chains to whip and jump teeth, and belts to slip, squeal, and wear quickly. On drives with fixed shaft centres, it may not be possible to move the motor or driven machine to restore tension. A tension arm solves this by applying constant, automatic tension, keeping the drive running smoothly throughout the life of the chain or belt.

Their main benefits are:

  • Automatic adjustment - takes up chain and belt stretch without manual re-tensioning
  • Longer chain and belt life - correct tension reduces wear on chains, belts, sprockets, and pulleys
  • Smoother running - controls slack and reduces vibration, whip, and flapping
  • Quieter drives - reduces chain slap and belt squeal
  • Shock absorption - the rubber element cushions start-up loads and sudden load changes
  • Less maintenance - no need for frequent adjustment, and no lubrication needed
  • Fixed-centre drives - keeps drives tensioned where motors and shafts cannot be moved
  • Reduced downtime - fewer drive problems and breakdowns

Tension arms are used across a wide range of industries and applications, including:

  • Conveyors - chain and belt drives on conveyor systems
  • Agricultural machinery - drives on balers, harvesters, drills, spreaders, and implements
  • Packaging and food machinery - chain and belt drives on production lines
  • Industrial machinery - mixers, feeders, and general power transmission
  • Material handling - transfer and handling equipment
  • Printing, paper, and textile machinery - chain and belt drives
  • Woodworking machinery - belt drives on saws and planers

The main types of tension arms

Tension arms are usually grouped by size, tensioning method, and the parts fitted to them.

By size:

  • Small tension arms - such as SE11 and SE15, for light-duty drives and smaller chains and belts
  • Medium tension arms - such as SE18, for general industrial and agricultural drives
  • Large tension arms - such as SE27 and above, for heavier drives, larger chains, and wider belts

By tensioning method:

  • Rubber element tension arms - use a rubber spring inside the housing to provide tension, absorb shock, and reduce vibration. They are compact and maintenance-free
  • Spring-loaded tension arms - use a coil or torsion spring to provide tension
  • Fixed or adjustable brackets - hold a sprocket or roller in a set position and are adjusted manually

By the part fitted:

  • Chain tension arms - fitted with a tension sprocket to suit the chain size, such as 06B, 08B, or 10B
  • Belt tension arms - fitted with a smooth or V-groove tension roller to suit the belt
  • Chain and belt tension arms - designed to accept either a sprocket or a roller, giving flexibility for different drives

Related products:

  • Tension sprockets - free-running sprockets with bearings, made to fit specific tension arm sizes
  • Tension rollers - free-running rollers for belts, made to fit specific tension arm sizes
  • Mounting brackets - help position tension arms on machine frames

How to choose the right tension arm?

Choosing the right tension arm means matching it to the drive and the parts that will be fitted to it. Work through these points in order:

  • Drive type - decide whether the tension arm will be used on a chain drive or a belt drive
  • Drive size and load - choose a larger tension arm for larger chains, wider belts, and heavier drives, as it provides more tensioning force
  • Chain or belt size - check that a suitable tension sprocket or roller is available for the tension arm size and your chain or belt
  • Tensioning force - make sure the arm provides enough force to keep the drive tight without overtightening it
  • Space available - check the arm length and housing size fit the space on the machine
  • Mounting - check the frame has a suitable mounting point, or plan for a mounting bracket
  • Thread size - check the thread size of the sprocket or roller mounting
  • Environment - consider dust, moisture, and temperature, as rubber element tensioners suit most general conditions
  • Quality and brand - choose tension arms from reputable suppliers for consistent tensioning force and long service life

How to fit a tension arm

Fitting a tension arm correctly helps the drive run smoothly:

  • Isolate the drive - switch off and isolate the machine before starting work
  • Fit the sprocket or roller - bolt the tension sprocket or roller to the end of the arm using the correct fixings
  • Choose the position - mount the arm so the sprocket or roller runs on the slack side of the chain or belt
  • Check the wrap - for chain drives, make sure the chain wraps around at least three teeth of the tension sprocket
  • Align it - make sure the sprocket or roller is in line with the drive and driven sprockets or pulleys
  • Set the preload - rotate the tension arm against the chain or belt to the angle recommended by the manufacturer, so the rubber element is preloaded, then tighten the mounting bolt to lock the housing in position
  • Leave room to move - make sure the arm has space to move as the chain or belt stretches
  • Check the drive - turn the drive by hand, then run it and check the chain or belt runs smoothly with the correct tension

FAQ - All you need to know about tension arms

What is a tension arm used for?

A tension arm holds a tension sprocket or roller against a chain or belt, keeping it at the correct tension automatically as it stretches and wears.

How does a rubber element tension arm work?

When the arm is rotated and locked in position, the rubber element inside the housing is twisted. The rubber pushes back, pressing the sprocket or roller against the chain or belt with a steady force.

What do SE11, SE15, SE18, and SE27 mean?

These are tension arm sizes. Larger sizes provide more tensioning force and suit larger chains, wider belts, and heavier drives.

Can a tension arm be used for chains and belts?

Yes. Chain and belt tension arms can be fitted with a tension sprocket for chain drives or a tension roller for belt drives.

Do I need to buy the sprocket or roller separately?

Usually, yes. Tension sprockets and rollers are made to fit specific tension arm sizes, so choose the one that matches your arm and your chain or belt.

Where should a tension arm be fitted?

It should be fitted so the sprocket or roller runs on the slack side of the chain or belt, which is the side not carrying the load.

How do I set the tension correctly?

Rotate the arm against the chain or belt to the preload angle recommended by the manufacturer, then tighten the mounting bolt. Avoid overtightening, as too much tension increases wear.

Do tension arms need maintenance?

Rubber element tension arms are maintenance-free in normal use. Check them regularly for damage, cracking, or loss of tension, and check the sprocket or roller bearings.

Why is my chain still slack with a tension arm fitted?

Common causes include a tension arm that is too small, incorrect preload, a chain that has stretched beyond the arm’s range, or a worn rubber element. Check the setting and consider a larger arm or a new chain.

When should I replace a tension arm?

Replace it if the rubber element has cracked, hardened, or lost its tension, if the housing or arm is damaged, or if it can no longer keep the chain or belt tight.
