Rotary Shaft Oil Seals
What is a rotary shaft oil seal?
A rotary shaft oil seal, also called a radial shaft seal or lip seal, is a ring-shaped seal fitted between a rotating shaft and its housing. It keeps oil or grease in, and dirt, dust, and water out. Oil seals are used wherever a shaft passes out of a gearbox, motor, pump, or bearing housing, and are one of the most common parts in machinery maintenance.
A standard oil seal has four main parts:
- A metal case, which gives the seal its strength and shape
- An outer surface, either rubber covered or bare metal, which seals against the housing bore
- A flexible sealing lip, usually made of rubber, which presses against the rotating shaft
- A garter spring, which wraps around the lip and keeps it pressed evenly against the shaft.
Many oil seals also have a second lip, called a dust lip.
- The main lip faces the oil side and keeps lubricant in.
- The dust lip faces outwards and helps keep dirt, dust, and water out, which protects the main lip and extends seal life.
Oil seals are sized by three dimensions: the shaft diameter, the housing bore diameter, and the seal width. For example, a 25x40x7 seal fits a 25mm shaft, in a 40mm bore, and is 7mm wide.
Why are rotary shaft oil seals essential?
Bearings, gears, and other moving parts need a steady supply of clean lubricant to work properly. An oil seal stops that lubricant leaking out where the shaft leaves the housing, and stops dirt and water getting in. A failed seal can quickly lead to oil loss, contaminated bearings, and expensive breakdowns.
Oil seals are compact, low in cost, and easy to replace, and they come in standard sizes in a wide choice of designs and materials. This means there is a seal to suit almost every shaft size, speed, temperature, and fluid.
Typical applications include:
- Gearboxes and reducers
- Electric motors and pumps
- Wheel hubs and axles
- Engines and transmissions
- Agricultural and construction machinery
- Bearing housings and plummer blocks
- Hydraulic motors and compressors
- Washing machines and household appliances
- Power tools and small engines
The main types of rotary shaft oil seals
- Single lip seals with rubber outer surface (SC / R21) - These have one sealing lip with a garter spring and a rubber-covered outer surface. They suit clean conditions where the main job is keeping oil in.
- Double lip seals with rubber outer surface (TC / R23) - These add a dust lip to the main lip. They are the most popular type, as they keep oil in and dirt out, and suit most general applications.
- Single lip seals with metal outer surface (SB) - These have a bare metal outer surface, for a firm press fit in accurately machined housings.
- Double lip seals with metal outer surface (TB) - The metal outer surface version of the double lip seal, with a dust lip for dirty conditions.
- Seals with an extra inner metal case (SA, TA) - These have a second metal case for extra strength, used in larger sizes and heavy-duty applications.
- Seals without a spring (VC and similar) - These have no garter spring, and are used for grease retention or low-pressure, low-speed applications.
- Branded designs - Manufacturers also offer their own designs, such as SKF HMS5 and HMSA10 metric seals and SKF CRW1 and CRWA1 inch seals, some with special lip profiles to reduce friction and heat.
Material variants include:
- Nitrile rubber (NBR) - The standard, general-purpose material. It resists mineral oils, greases, fuels, and water, and is suited to temperatures up to around 100°C.
- Fluoroelastomer (FKM) - For higher temperatures, up to around 200°C, and better chemical resistance.
- Silicone (VMQ) - For a wide temperature range, but less resistant to wear and some oils.
- PTFE - For very high speeds, chemicals, dry running, or where low friction is needed.
How to choose the right rotary shaft oil seal?
- Size - Measure the shaft diameter, the housing bore diameter, and the width of the space for the seal. All three must match.
- Lip type - Choose a single lip seal for clean conditions, or a double lip seal where dirt, dust, or water could get in.
- Outer surface - Rubber-covered seals are easier to fit and seal better in housings with a rougher finish. Metal outer surface seals give a firmer fit in accurately machined housings.
- Material - Choose nitrile for most applications, FKM for higher temperatures or aggressive fluids, and PTFE for very high speeds or chemicals. Check the material is compatible with the oil or fluid being sealed.
- Speed, pressure, and temperature - Standard oil seals are designed for low or no pressure. For high speeds, high temperatures, or pressure, choose a seal designed for those conditions.
- Shaft condition - The shaft must be smooth, hard, and free from scratches or grooves where the lip runs. A worn shaft can be repaired with a shaft repair sleeve.
Essential references and specialised ranges
How the numbering works:
Oil seals are referenced by size and type:
The size is given as shaft diameter x housing bore x width, in mm for metric seals. For example, 25x40x7 fits a 25mm shaft, in a 40mm bore, and is 7mm wide.
Inch seals are sized the same way, in inches.
The type code describes the seal design. In the widely used two-letter system:
The first letter describes the lip:
S = single lip with garter spring
T = double lip (main lip and dust lip) with garter spring
V = single lip without garter spring
The second letter describes the outer surface:
C = rubber-covered outer surface
B = metal outer surface
A = metal outer surface with an extra inner metal case
So a TC seal is a double lip seal with a rubber-covered outer surface. A full reference might read 25x40x7 TC NBR.
Suffixes:
R21 = single lip seal with rubber outer surface, equivalent to SC
R23 = double lip seal with rubber outer surface, equivalent to TC
NBR = nitrile rubber
FKM = fluoroelastomer
Suffix codes vary between manufacturers, so check the supplier’s catalogue for the exact meaning.
FAQ - All you need to know about rotary shaft oil seals
Which way round does an oil seal go?
The side with the garter spring usually faces the oil or grease being sealed. On double lip seals, the dust lip faces outwards, towards the dirt.
What is the difference between TC and SC seals?
A TC seal has two lips: a main lip to keep oil in and a dust lip to keep dirt out. An SC seal has only the main lip, so it suits clean conditions where dirt is not a problem.
Can oil seals take pressure?
Standard oil seals are designed for little or no pressure, usually just splash or bath lubrication. If the seal will be under pressure, choose a seal designed for pressure, as a standard lip can be pushed off the shaft and leak.
Do oil seals need lubrication?
Yes. The lip relies on a thin film of oil or grease to run without wearing or overheating. Lightly lubricate the lip before fitting, and never run a standard seal dry.
How do I fit an oil seal?
Clean the housing bore and shaft, and check for burrs or sharp edges. Lightly oil the seal lip and outer surface, then press the seal in squarely using a seal driver or a tube that pushes evenly on the outer edge. Protect the lip from sharp edges, keyways, and threads as it passes over the shaft. Never hammer directly on the seal.
How do I identify an oil seal I need to replace?
The size and type are often marked on the seal face. If they cannot be read, measure the shaft diameter, the housing bore diameter, and the seal width. Also note whether it has one or two lips, a rubber or metal outer surface, and what colour the rubber is, as this can show the material.
How can I tell if an oil seal is worn or failing?
Warning signs include:
- Oil or grease leaking from around the shaft
- Dirt, water, or grit getting into the housing
- A hardened, cracked, or split sealing lip
- A missing or broken garter spring
- A groove worn into the shaft where the lip runs
- The seal moving or spinning in the housing bore
