What are key steel and silver steel?

Key steel and silver steel are precision bar stock materials used in engineering, maintenance, toolmaking, and model engineering. Both are made to close tolerances, so they can be used straight from the bar or cut and finished to make accurate parts with very little machining.

Key steel is used to make and fit keys, which lock pulleys, gears, sprockets, and couplings onto shafts. It is available as precision bar stock in square and rectangular sections, which can be cut to length, and as ready-made keys, such as feather keys with rounded or square ends. A key sits partly in a keyway cut into the shaft and partly in a keyway cut into the hub, stopping the hub turning on the shaft so that torque can be transmitted.

Silver steel is a high-carbon tool steel supplied as precision ground round bar. Despite its name, it contains no silver. It is called silver steel because of its bright, polished appearance. It can be machined in its supplied state and then hardened and tempered, making it ideal for shafts, pins, punches, tools, and wear parts.

Key steel and keys are usually described by:

  • Width - the width of the key, which must match the keyway width
  • Height - the height of the key, which sits in both the shaft and the hub keyway
  • Length - the length of the key or bar
  • End form - such as two rounded ends, two square ends, or one rounded and one square end
  • Standard - such as DIN 6885 for parallel keys

For example, a DIN 6885 feather key with two rounded ends, sized 2 × 2 × 10 mm, is 2 mm wide, 2 mm high, and 10 mm long.

Silver steel is usually described by:

  • Diameter - the ground diameter of the bar, in metric or imperial sizes
  • Length - the length of the bar
  • Tolerance - the accuracy to which the diameter is ground

Key features:

  • Precision tolerances - accurately sized for close-fitting keys, shafts, and pins
  • Ready to use - keys can be fitted straight away, and bar can be cut to length
  • Strong and durable - key steel resists shear and wear in power transmission
  • Hardenable - silver steel can be hardened and tempered after machining
  • Bright, clean finish - smooth surfaces for accurate fits and a neat appearance
  • Metric and imperial sizes - to suit modern and older equipment
  • Range of materials - carbon steel, stainless steel, and other options for keys

In simple terms, key steel locks hubs onto shafts, and silver steel provides precise, hardenable round bar for shafts, pins, and tools.

Why are key steel and silver steel essential?

Key steel and silver steel are essential because power transmission and precision engineering depend on accurate, close-fitting parts. A loose or poorly fitting key can let a pulley or gear move on its shaft, causing wear, noise, damaged keyways, and loss of drive. Badly sized shafts and pins can cause play, misalignment, and early wear. Using precision key steel and silver steel ensures parts fit correctly and perform reliably.

Their main benefits are:

  • Secure torque transmission - correctly fitted keys stop hubs slipping on shafts
  • Accurate fits - close tolerances give a tight, reliable fit in keyways, bores, and housings
  • Reduced wear - well-fitting keys and shafts reduce fretting, keyway damage, and play
  • Quick repairs - ready-made keys and bar stock let worn parts be replaced quickly
  • Custom parts - bar stock can be cut and machined to make keys, pins, and shafts of any length
  • Hardenable tooling - silver steel can be hardened to make strong, wear-resistant tools and parts
  • Cost-effective - precision stock reduces machining time and waste

Key steel and silver steel are used across a wide range of industries and applications, including:

  • Power transmission - keys for pulleys, sprockets, gears, and couplings
  • Motors and gearboxes - keys for motor shafts and gearbox drives
  • Maintenance and repair - replacing worn or sheared keys
  • Agricultural machinery - drive shafts, pulleys, and gearboxes
  • Toolmaking - punches, drifts, scribers, and cutting tools made from silver steel
  • Precision engineering - shafts, pins, guides, and spindles
  • Model engineering - small shafts, axles, and precision parts
  • Manufacturing - jigs, fixtures, and locating pins

The main types of key steel and silver steel

Key steel and silver steel are usually grouped by their form, end shape, material, and standard.

Parallel keys (feather keys):

  • Keys with two rounded ends - fit keyways with rounded ends, such as those cut with an end mill. Commonly known as DIN 6885 form A keys
  • Keys with two square ends - fit keyways with square ends or open-ended keyways. Commonly known as DIN 6885 form B keys
  • Keys with one rounded and one square end - suit keyways that are rounded at one end and open at the other

Key steel bar:

  • Square key steel - equal width and height, such as 6 × 6 mm, supplied in lengths to cut keys as needed
  • Rectangular key steel - different width and height, such as 8 × 7 mm or 10 × 8 mm, used for larger shafts
  • Metric key steel - sized in millimetres for metric shafts and keyways
  • Imperial key steel - sized in inches for imperial shafts and keyways

Other key types:

  • Woodruff keys - half-moon shaped keys that sit in a curved keyway in the shaft, often used on tapered shafts and smaller drives
  • Taper keys - keys with a slight taper that are driven in to lock the hub tightly
  • Gib head keys - taper keys with a head that makes them easier to remove

Silver steel:

  • Silver steel round bar - precision ground high-carbon tool steel, supplied in metric and imperial diameters
  • Silver steel in standard lengths - commonly supplied in convenient lengths that can be cut to size

By material:

  • Carbon steel - the standard material for keys and key steel, giving good strength and wear resistance
  • Stainless steel - corrosion-resistant keys and key steel for food, marine, and washdown environments
  • Brass - softer keys used where the key should wear or shear before the shaft or hub
  • High-carbon tool steel - used for silver steel, allowing it to be hardened and tempered

How to choose the right key steel and silver steel?

Choosing the right key steel or silver steel means matching it to the shaft, keyway, and job. Work through these points in order:

  • Shaft diameter - for keys, the shaft diameter sets the standard key size. As a guide, DIN 6885 uses 2 × 2 mm keys for shafts over 6 to 8 mm, 4 × 4 mm for over 10 to 12 mm, 6 × 6 mm for over 17 to 22 mm, 8 × 7 mm for over 22 to 30 mm, 10 × 8 mm for over 30 to 38 mm, and 12 × 8 mm for over 38 to 44 mm
  • Keyway width and depth - measure the keyway in the shaft and hub, and choose a key that matches the width and height
  • Key length - choose a length that fits the keyway and hub, usually slightly shorter than the hub length
  • End form - choose rounded ends for keyways with rounded ends, and square ends for square-ended or open keyways
  • Ready-made key or bar - choose ready-made keys for standard sizes and quick fitting, or key steel bar to cut keys to a custom length
  • Metric or imperial - match the key or bar to the shaft and keyway sizes
  • Material - choose carbon steel for general use, stainless steel for corrosive environments, and brass where a softer key is preferred
  • Silver steel diameter - choose a diameter that matches the bore, bush, or part you are making, allowing for any finishing needed
  • Hardening - choose silver steel if the part needs to be hardened and tempered after machining
  • Quality and brand - choose key steel and silver steel from reputable suppliers for accurate tolerances and consistent material

How to fit a key

Fitting a key correctly helps it transmit torque reliably:

  • Clean the keyways - remove dirt, burrs, and old key material from the shaft and hub keyways
  • Check the fit - the key should fit the shaft keyway snugly, without being forced or loose
  • Cut to length - if using key steel, cut the key to length and remove any burrs, then round or chamfer the ends if needed
  • Fit the key - tap the key gently into the shaft keyway, keeping it straight and level
  • Fit the hub - slide the pulley, gear, or coupling onto the shaft and over the key, keeping the keyways aligned
  • Secure the hub - lock the hub in position with a set screw, collar, or locking bush, as the key alone does not stop the hub sliding along the shaft

FAQ - All you need to know about key steel and silver steel

What is a key used for?

A key sits in matching keyways in a shaft and hub, locking them together so the shaft can transmit torque to a pulley, gear, sprocket, or coupling.

What is a feather key?

A feather key is a parallel key that locks a hub to a shaft. It is commonly made to standards such as DIN 6885, with rounded or square ends.

What does DIN 6885 mean?

DIN 6885 is a standard for parallel keys and keyways. It sets the dimensions of keys and keyways for different shaft diameters, so parts from different suppliers fit together correctly.

What do the sizes on a key mean?

Key sizes are usually given as width × height × length. For example, a 2 × 2 × 10 mm key is 2 mm wide, 2 mm high, and 10 mm long.

How do I know what size key I need?

Measure the width of the keyway, or check the shaft diameter against a key size chart, such as DIN 6885. Then choose the matching key height and length.

What is the difference between rounded and square end keys?

Rounded end keys fit keyways with rounded ends, usually cut with an end mill. Square end keys fit square-ended or open keyways.

What is silver steel?

Silver steel is a high-carbon tool steel supplied as precision ground round bar. It is named for its bright finish and contains no silver.

Can silver steel be hardened?

Yes. Silver steel can be machined in its supplied state, then hardened by heating and quenching, and tempered to reduce brittleness and set the required hardness.

What is silver steel used for?

It is used for shafts, pins, axles, punches, drifts, scribers, small tools, and precision parts, especially in toolmaking and model engineering.

Why does my key keep shearing?

Common causes include overloading, shock loads, a key that is too small or too short, a loose fit in the keyway, or a hub that is not secured properly. Check the key size, keyway condition, and hub fit.

Why is my pulley loose even though the key fits?

A key stops the hub rotating on the shaft but does not stop it sliding along the shaft. Make sure the hub is also secured with a set screw, collar, or locking bush, and check for worn keyways or shaft damage.
