Duplex Sprockets

What is a duplex sprocket?

A duplex sprocket is a sprocket with two rows of teeth, designed to run with duplex roller chain. Duplex chain has two rows of rollers side by side, giving more strength and power capacity than simplex chain, and the matching duplex sprocket has two closely spaced rows of teeth to engage both strands at once. Duplex sprockets are used in industrial drives that need to transmit more power than simplex chain can handle, without moving to a larger chain pitch.

The duplex sprockets in this range have a hub and a pilot bore. The pilot bore is a small starter hole that can be machined out to fit the exact shaft size, with a keyway and set screw added as needed. This makes them versatile for new drives, repairs, and custom applications.

A typical duplex sprocket has:

• Two rows of teeth - matched to the pitch, roller size, and strand spacing of duplex roller chain
• Hub - an extended boss that supports the sprocket on the shaft and provides room for a keyway and set screw
• Pilot bore - a small starter bore that can be machined to the required shaft size
• Steel body - strong and durable, often with hardened teeth for longer wear life

Duplex sprockets are usually described by:

• Chain size - such as 06B-2 for 3/8 inch pitch, 08B-2 for 1/2 inch pitch, or 10B-2 for 5/8 inch pitch British Standard duplex chain
• Number of teeth - such as 8, 9, 10, or 18 teeth, which sets the sprocket size and drive ratio
• Bore type - such as pilot bore, ready to be machined to size
• Pitch circle diameter - the effective working diameter of the sprocket

For example, an 18 tooth 08B duplex pilot bore sprocket has 18 teeth, suits 1/2 inch pitch British Standard duplex chain, and has a pilot bore that can be machined to fit the shaft.

Key features:

• Duplex chain compatibility - two rows of teeth for higher-power duplex chain drives
• Higher torque transmission - carries more power than simplex sprockets of the same pitch
• Pilot bore - can be machined to fit the shaft exactly, with a keyway and set screw added
• Hub design - gives a solid, stable mounting on the shaft
• Compact - more power without moving to a larger chain pitch and bigger sprockets
• Steel construction - strong and durable for industrial drives
• Range of sizes - available in many tooth counts and chain sizes

In simple terms, a duplex sprocket is a two-row sprocket that drives duplex chain, giving more power than simplex chain in a compact drive.

Why are duplex sprockets essential?

Duplex sprockets are essential for drives that need more power than simplex chain can provide, but where space or speed makes a larger pitch chain unsuitable. Larger pitch chains need bigger sprockets and run less smoothly at higher speeds. Duplex sprockets and chain allow a smaller pitch to carry more power, keeping drives compact, smooth running, and reliable.

Their main benefits are:

• More power in a compact drive - higher capacity than simplex sprockets of the same pitch
• Smoother running - smaller pitches with two strands can run more smoothly than larger single-strand chains
• Positive drive - no slipping, keeping drives accurate and reliable
• Durable - handles heavy loads, shock, and continuous operation
• Custom bores - pilot bores can be machined to suit any shaft size within the sprocket’s range
• Strong mounting - the hub gives a secure fit on the shaft with a key and set screw
• Widely available - standard sizes make replacement sprockets easy to source

Duplex sprockets are used across a wide range of industries and applications, including:

• Industrial drives - medium and heavy-duty chain drives on machinery
• Conveyors - conveyor drives and transfer systems
• Agricultural machinery - drives on harvesters, balers, drills, and processing equipment
• Packaging and food machinery - drive systems on production lines
• Mining and quarrying - conveyors, screens, and crushers
• Pumps, compressors, and mixers - chain-driven equipment
• Timber, paper, and steel processing - drive systems and conveyors

The main types of duplex sprockets

Duplex sprockets are usually grouped by chain standard, chain size, tooth count, and bore type.

By chain standard:

• British Standard (BS) duplex sprockets - suit European-style duplex roller chains, such as 06B-2, 08B-2, 10B-2, 12B-2, and 16B-2
• ANSI duplex sprockets - suit American-style duplex roller chains, such as 35-2, 40-2, 50-2, 60-2, and 80-2

British Standard and ANSI chains are not interchangeable, so the sprocket must match the chain standard.

By chain size:

• 06B-2 (3/8 inch pitch) sprockets - for compact medium-duty drives
• 08B-2 (1/2 inch pitch) sprockets - a popular size for general industrial drives
• 10B-2 (5/8 inch pitch) sprockets - for higher power drives
• 12B-2 (3/4 inch pitch) and larger sprockets - for heavy-duty drives

By number of teeth:

• Small sprockets - fewer teeth, used as drive sprockets on motors and gearboxes where space is limited
• Large sprockets - more teeth, used as driven sprockets to reduce speed and increase torque, and for smoother running

By bore type:

• Pilot bore sprockets - supplied with a small starter bore, ready to be machined to the exact shaft size, with a keyway and set screw added as needed
• Tapered bore sprockets - designed to accept a tapered locking bush for quick, keyless mounting

Related products:

• Duplex tapered bore sprockets - duplex sprockets designed for tapered locking bushes
• Duplex platewheels - hubless duplex sprockets that can be bored, welded, or bolted
• Double simplex sprockets - sprockets with two widely spaced tooth rows for driving two separate simplex chains
• Duplex chain and links - matching chain and connecting links for duplex drives

How to choose the right duplex sprocket?

Choosing the right duplex sprocket means matching it to the chain, the shaft, and the drive. Work through these points in order:

• Chain standard - check whether the drive uses British Standard or ANSI duplex chain
• Chain size - choose a sprocket that matches the chain pitch exactly, such as 06B-2 or 08B-2
• Number of strands - make sure the sprocket is duplex, with two closely spaced rows of teeth for a single duplex chain. For two separate simplex chains, choose a double simplex sprocket instead
• Number of teeth - choose tooth counts on the drive and driven sprockets that give the required ratio. As a guide, larger tooth counts give smoother running and less chain wear, especially at higher speeds
• Bore - check the pilot bore can be machined to your shaft size, leaving enough material in the hub for strength and a keyway
• Fixing method - plan how the sprocket will be fixed to the shaft, usually with a key and set screw
• Load and speed - check the chain size and sprocket suit the power and speed of the drive
• Space - check the pitch circle diameter, hub, and overall width fit the available space
• Quality and brand - choose sprockets from reputable suppliers for accurate teeth and reliable performance

How to fit a duplex sprocket

Fitting a duplex sprocket correctly helps the chain run smoothly:

• Machine the bore - bore the sprocket to the shaft size, keeping the bore concentric with the teeth
• Cut a keyway - add a keyway to suit the shaft key, and drill and tap a hole for a set screw if needed
• Isolate the drive - switch off and isolate the machine before fitting
• Fit to the shaft - slide the sprocket onto the shaft with the key in place
• Align the sprocket - position the sprocket so it lines up with the sprocket it drives, using a straight edge across the faces
• Secure the sprocket - tighten the set screw onto the key or shaft to stop the sprocket moving along the shaft
• Fit the chain - fit the duplex chain and set the tension, leaving a small amount of slack on the slack side
• Check the drive - turn the drive by hand to check the chain runs smoothly, then lubricate before running

FAQ - All you need to know about duplex sprockets

What is a duplex sprocket?

A duplex sprocket is a sprocket with two rows of teeth, designed to run with duplex roller chain in drives that need more power than simplex chain can provide.

What does pilot bore mean?

A pilot bore is a small starter hole in the centre of the sprocket. It is designed to be machined out to the exact shaft size, usually with a keyway and set screw added.

What does 06B mean on a duplex sprocket?

06B is the British Standard chain size for 3/8 inch pitch chain. A duplex sprocket marked 06B suits 06B-2 duplex roller chain.

What is the difference between duplex and double simplex sprockets?

A duplex sprocket has two closely spaced tooth rows for a single duplex chain. A double simplex sprocket has two tooth rows spaced further apart, so two separate simplex chains can run side by side.

Can I use a duplex sprocket with simplex or triplex chain?

No. Duplex sprockets have two rows of teeth and are designed to run with duplex chain only.

What is the difference between BS and ANSI sprockets?

BS sprockets suit British Standard chain, and ANSI sprockets suit American Standard chain. They have different tooth dimensions and are not interchangeable.

What is the difference between pilot bore and tapered bore sprockets?

Pilot bore sprockets are machined to fit the shaft and fixed with a key and set screw. Tapered bore sprockets accept a tapered locking bush, giving quick, keyless mounting and allowing one sprocket to fit different shaft sizes.

How do I work out the drive ratio?

Divide the number of teeth on the driven sprocket by the number of teeth on the drive sprocket. For example, an 18 tooth drive sprocket and a 54 tooth driven sprocket give a 3:1 ratio, reducing speed to a third and increasing torque.

Why should I avoid very small sprockets?

Sprockets with very few teeth cause the chain to bend more sharply, which increases wear, vibration, and noise. Where space allows, larger sprockets give smoother running and longer chain life.

Do duplex sprockets need lubrication?

The chain running on the sprocket should be lubricated regularly to reduce wear. The sprocket itself does not need separate lubrication.

When should I replace a duplex sprocket?

Replace it if the teeth are hooked, pointed, or worn, as worn sprockets quickly wear new chain. It is good practice to check sprockets whenever the chain is replaced.
