• SKF FYT20TFVA201 Y Bearing Two Bolt Oval High Temperature Flange Unit Housing with Steel Cage Insert for Metric Shaft 20mm
1 1

SKU: FYT20TF/VA201-SKF

SKF FYT20TFVA201 Y Bearing Two Bolt Oval High Temperature Flange Unit Housing with Steel Cage Insert for Metric Shaft 20mm

SKF FYT20TFVA201 Y Bearing Two Bolt Oval High Temperature Flange Unit Housing with Steel Cage Insert for Metric Shaft 20mm
CHF 120.00 ex VAT
CHF 120.00 ex VAT
Sale Sold out

In stock

Price Break
10+ CHF 95.56
19+ CHF 90.19
29+ CHF 89.11
39+ CHF 88.04
49+ CHF 86.97
74+ CHF 85.89
99+ CHF 80.53
199+ CHF 79.45
249+ CHF 78.38
499+ CHF 77.30
999+ CHF 75.16
Request Quotation

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
SKF High Temperature Housings and Bearing Inserts: VA201 have a grey cast iron housing and have steel cages, they are lubricated with a polyalkylene glycol/graphite mixture and can be used at temperatures from -40 deg to +250 deg Celsius, at prolonged use over 200 deg Celsius dry lubricant pertains. All versions are characterised by their BLACK PHOSPHATED COATING on the inserts.They have a max rotational speed of 100 rpm
Benefits:High temp tolerance from -40 to +250 deg Celsius
Brand / Quality:
SKF - High Quality
Inside Diameter:
20mm
Temperature Range:
High Temp
Technical
d 20mm
A1 24.6mm
A2 11.11mm
B 31mm
H 112mm
J 89.7mm
L 60.5mm
N 11.1mm
G 10mm
T 32.6mm
Dynamic load C 12.7 kN
Static load Co 6.55 kN
Weight 0.5 kg
