SKU: MSF100-RHP
RHP MSF100 Metric Four Bolt Square Cast Iron Flange Housing and 100mm Bore Grub Screw Insert
RHP MSF100 Metric Four Bolt Square Cast Iron Flange Housing and 100mm Bore Grub Screw Insert
Regular price
CHF 803.00
ex VAT
Regular price
Sale price
CHF 803.00
ex VAT
In stock
Price Break
10+
CHF 639.88
20+
CHF 603.94
30+
CHF 596.75
40+
CHF 589.56
50+
CHF 582.37
75+
CHF 575.18
100+
CHF 539.23
200+
CHF 532.04
250+
CHF 524.85
500+
CHF 517.66
1000+
CHF 503.28
Share this product
Description
Description
|
RHP MSF Series Heavy Duty 4 Bolt Square Cast Iron Housings: Bearing units supplied with a full width sealed heavy duty bearing insert fitted in the cast iron housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has two grub screws to allow tightening against the shaft after installation. |
- Brand / Quality:
- RHP - High Quality
- Inside Diameter:
- 100mm
- Style:
- MSF
- Bolt Hole Centres:
- 211.12mm
Technical
Technical
| Bore | 100mm |
|---|---|
| L | 267.5mm |
| H | 235.5mm |
| J | 211.12mm |
| G | 24mm |
| A | 83.5mm |
| A1 | 126.95mm |
| A4 | 32mm |
| B | 117.48mm |
| s | 49.27mm |
| d1 | 130.43mm |
| Dynamic load cr | 157000 N |
| Static load Cor | 122020 N |
| Rec max speed | 1600 rpm |
| Weight | 24.7 kg |
| Insert | <a href="advanced_search_result.php?keywords=3095-100G+insonly">3095-100G Click Here</a> |
| Casting group | 13 |
| Grease nipple thread | 1/4 UNF, 1/4 inch x 28 TPI |
