SKU: NJ2215ECP/C3-SKF
SKF NJ2215ECPC3 Single Row Cylindrical Roller Bearing with Polyamide Cage 75x130x31mm
SKF NJ2215ECPC3 Single Row Cylindrical Roller Bearing with Polyamide Cage 75x130x31mm
Regular price
CHF 164.00
ex VAT
Regular price
Sale price
CHF 164.00
ex VAT
In stock
Price Break
10+
CHF 129.93
19+
CHF 122.64
29+
CHF 121.18
39+
CHF 119.72
49+
CHF 118.26
74+
CHF 116.80
99+
CHF 109.50
199+
CHF 108.04
249+
CHF 106.58
499+
CHF 105.12
999+
CHF 102.20
Description
Description
|
SKF NJ Series Single Row Cylindrical Roller Bearings: The outer ring of this type has two integral flanges around which the cage and rollers are assembled, the inner raceway has a single flange permitting the ease of assembly but limiting axial location to one direction. Benefits: Axial location, ease of assembly and fitting |
- Brand / Quality:
- SKF - High Quality
- Inside Diameter:
- 75mm
- Outside Diameter:
- 130mm
- Width:
- 31mm
- Seals / Shields:
- None
- Clearance:
- C3
Technical
Technical
| d | 75mm |
|---|---|
| D | 130mm |
| B | 31mm |
| Dynamic load C | 186 kN |
| Static load Co | 208 kN |
| Fatigue load limit Pu | 27 kN |
| Reference speed | 5600 rpm |
| Limiting speed | 6000 rpm |
| Weight | 1.6 kg |
| Alt cage | J.ML |
| d1 | 94.3mm |
| D1 | 114mm |
| F,E | 88.5mm |
| r1r2 min | 1.5mm |
| r3r4 min | 1.5mm |
| S | 1.7mm |
| da min | 84mm |
| da max | 86mm |
| db | 97mm |
| Da max | 121mm |
| ra max | 1.5mm |
| rb max | 1.5mm |
| kr | 0.2 |
