SKU: 08B-1-25FT-SS
Branded Stainless Steel 08B-1 BS Simplex Roller Chain 25 Foot 1/2 Inch Pitch
Branded Stainless Steel 08B-1 BS Simplex Roller Chain 25 Foot 1/2 Inch Pitch
Regular price
CHF 281.00
ex VAT
Regular price
Sale price
CHF 281.00
ex VAT
In stock
Price Break
10+
CHF 223.28
19+
CHF 210.73
29+
CHF 208.22
39+
CHF 205.71
49+
CHF 203.21
74+
CHF 200.70
99+
CHF 188.15
199+
CHF 185.64
249+
CHF 183.14
499+
CHF 180.63
999+
CHF 175.61
Description
Description
Major Branded Roller Chain: Manufactured to BS228, ISO 606, DIN8187, DIN8188 standards with hardened pins which prevent wear and stretch and also make it easy to dismantle. Roller chains are designed for demanding industrial and agricultural drives. Consistent quality, high-quality product.
Comprehensive range of simplex, duplex and triplex roller chains in British standard and American standard. Heavy-duty American standard roller chains are also available for extra tough conditions.
- Brand / Quality:
- Major Brand - High Quality
- Pitch:
- 12.7mm = 0.5 (1/2) inch
Technical
Technical
| Pitch (P) | 12.70mm = 1/2 inch |
|---|---|
| Roller Diameter (D1 max) | 8.51mm |
| Width between inner plates (B1 min) | 7.75mm |
| Pin dia meter (D2 max) | 4.45mm |
| Pin length (L max) | 16.7mm |
| Pin length (Lc max) | 18.2mm |
| Inner plate depth (H2 max) | 11.8mm |
| Plate thickness (T max) | 1.6mm |
| Ultimate tensile strength (Q min) kN/LB | 18.0/4091 |
| Average tensile strength (Q0) kN | 19.4 |
| Weight per meter (q) kg/m | 0.69 |
