SKU: 100-3-SYNERGY-10FT-RENOLD
Renold Synergy 100-3 ANSI / AS Triplex Roller Chain 1-1/4 inch Pitch - 10 Feet Length
Renold Synergy 100-3 ANSI / AS Triplex Roller Chain 1-1/4 inch Pitch - 10 Feet Length
Regular price
CHF 2,859.14
ex VAT
Regular price
Sale price
CHF 2,859.14
ex VAT
Equivalent to: GY100A3
In stock
Price Break
10+
CHF 2,544.63
19+
CHF 2,401.68
29+
CHF 2,373.09
39+
CHF 2,344.49
49+
CHF 2,315.90
74+
CHF 2,287.31
99+
CHF 2,144.36
199+
CHF 2,115.76
249+
CHF 2,087.17
499+
CHF 2,058.58
999+
CHF 2,001.40
Couldn't load pickup availability
Description
Description
Renold Synergy High Performance Chain: Renold Synergy chain will last three times longer in normal working conditions than your current non-Renold chain or your next chain is free. It's that simple. If the working life of your non Renold Chain is unsatisfactory, try Renold Synergy®. You will see productivity increase, downtime cut and costs saved. Renold are so confident that their chain will significantly outlast any other non-Renold brand chain that we will give you a replacement chain free*. There has never been a better time to specify Renold Synergy® - the only high performance transmission chain.
Equivalent: GY100A3
* Subject to site visit from a Renold Service Engineer
Renold Synergy® has transformed the productivity and efficiency of all these industrial applications and more.
Equivalent: GY100A3
- Brand / Quality:
- Renold - High Quality
- Pitch:
- 31.75mm = 1.25 (1-1/4) inch
Technical
Technical
| Pitch (A) | 1.25 inch |
|---|---|
| Pitch (A) | 31.75mm |
| Inside Width min (B) | 18.9mm |
| Roller Diameter max (C) | 19.05mm |
| Plate Height max (D) | 30.17mm |
| Plate Width Inner max (E) | 4.06mm |
| Plate Width Outer max (F) | 4.06mm |
| Pin Diameter max (G) | 9.54mm |
| Pin Length max (H1) | 111.2mm |
| Connecting Link Extension max (J) | 4.2mm |
| ISO606 Tensile Strength min | 261000 N |
| Weight | 12.6kg/m |
