SKU: 1250-50G-RHP

RHP 1250-50G Spherical Outer Flat Back Bearing Insert 50mm Bore 90mm Outside Diameter

Name: RHP 1250-50G Spherical Outer Flat Back Bearing Insert 50mm Bore 90mm Outside Diameter
Brand: RHP
SKU: 1250-50G-RHP
Price: 56.00 CHF
Availability: InStock

CHF 56.00 ex VAT

Sale Sold out

In stock

Price Break

10+ CHF 44.49

20+ CHF 41.99

30+ CHF 41.49

40+ CHF 40.99

50+ CHF 40.49

75+ CHF 39.99

100+ CHF 37.49

200+ CHF 36.99

250+ CHF 36.49

500+ CHF 35.99

1000+ CHF 34.99

Request Quotation

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More

Description

RHP 1000 G Series: Flat back bearing insert with spherical outer race and and 2 grub screws 120 degrees apart to allow tightening against the shaft once fitted. These inserts are ideal replacements for housed types which can easily be removed from the housings when replacement is required
Benefits: Cost effective replacement insert, re-lubricatable, grub screw fixing

Brand / Quality:: RHP - High Quality
Inside Diameter:: 50mm
Outside Diameter:: 90mm
Style:: 1250

Technical

Bore	50mm
D	90mm
C	20mm
B1	43.54mm
s1	11.05mm
d1	62.2mm
M	8.95mm
r	1mm
Dynamic load Cr	35000 N
Static load Cor	23200 N
Rec max speed	3400 rpm
Weight	0.76 kg
