SKU: 30222J2-SKF
SKF 30222J2 Metric Single Row Taper Roller Bearing 110x200x41mm
SKF 30222J2 Metric Single Row Taper Roller Bearing 110x200x41mm
Regular price
CHF 278.50
ex VAT
Regular price
Sale price
CHF 278.50
ex VAT
In stock
Price Break
10+
CHF 247.87
19+
CHF 233.94
29+
CHF 231.16
39+
CHF 228.37
49+
CHF 225.59
74+
CHF 222.80
99+
CHF 208.88
199+
CHF 206.09
249+
CHF 203.31
499+
CHF 200.52
999+
CHF 194.95
Couldn't load pickup availability
Description
Description
|
SKF Taper Roller Bearings: These bearings have tapered inner and outer raceways between which tapered roller are arranged. The design of taper rollers makes them particularly suited to accommodating combined axial and radial loads. They are supplied as a cup and cone set (inner and outer). Benefits: Used widely in transmissions, can be used in oil or greased, high radial and axial load |
- Brand / Quality:
- SKF - High Quality
- Inside Diameter:
- 110mm
- Outside Diameter:
- 200mm
- Width:
- 41mm
- Seals / Shields:
- None
Technical
Technical
| d | 110mm |
|---|---|
| D | 200mm |
| T | 41mm |
| Dynamic load | 308 kN |
| Static load | 405 kN |
| Fatigue load limit Pu | 45 kN |
| Reference speed | 2400 rpm |
| Limiting speed | 3200 rpm |
| Weight | 5.1 kg |
| d1 | 148mm |
| B | 38mm |
| C | 32mm |
| r1r2 min | 3mm |
| r3r4 min | 2.5mm |
| a | 39mm |
| da max | 129mm |
| db min | 122mm |
| Da min | 174mm |
| Da max | 188mm |
| Db min | 187mm |
| Ca min | 6mm |
| Cb min | 9mm |
| ra max | 2.5mm |
| rb max | 2mm |
| Calculation factor e | 0.43 |
| Calculation factor Y | 1.4 |
| Calculation factor Y0 | 0.8 |
