SKU: 310NR-SKF
SKF 310NR Open Type Filling Slot Ball Bearing and Snap Ring 50x110x27mm
SKF 310NR Open Type Filling Slot Ball Bearing and Snap Ring 50x110x27mm
Regular price
CHF 134.17
ex VAT
Regular price
Sale price
CHF 134.17
ex VAT
In stock
Price Break
10+
CHF 119.41
19+
CHF 112.70
29+
CHF 111.36
39+
CHF 110.02
49+
CHF 108.68
74+
CHF 107.34
99+
CHF 100.63
199+
CHF 99.29
249+
CHF 97.94
499+
CHF 96.60
999+
CHF 93.92
Couldn't load pickup availability
Description
Description
|
SKF Filling Slot Ball Bearings with Snap Ring: Are special variants of deep groove ball bearings which have filling slots to allow at point of manufacture more and larger balls to be used in the assembly. Filling slot bearings have a higher radial load carrying capacity than bearings without slots but their axial load carrying capacity is reduced. Their speed rating is lower than bearings without slots. This option is supplied with snap ring groove and snap ring. Benefits: Tolerates high radial loads |
- Brand / Quality:
- SKF - High Quality
- Inside Diameter:
- 50mm
- Outside Diameter:
- 110mm
- Width:
- 27mm
- Seals / Shields:
- None
- Clearance:
- * Standard
- Snap Ring:
- Snap Ring
Technical
Technical
| d | 50mm |
|---|---|
| D | 110mm |
| B | 27mm |
| Dynamic load C | 64.4 kN |
| Static load Co | 52 kN |
| Fatigue load limit Pu | 2.2 kN |
| Reference speed | 11000 rpm |
| Limiting speed | 7000 rpm |
| Weight | 1.15 kg |
| Snap ring | SP110 |
| d1 | 62.5mm |
| D2 | 95.2mm |
| D3 | 106.81mm |
| D4 | 116.6mm |
| f | 2.46mm |
| b | 2.7mm |
| C | 3.28mm |
| ro max | 0.6mm |
| r1r2 min | 2mm |
| da min | 61mm |
| Da max | 99mm |
| Db min | 118mm |
| ba min | 3mm |
| Ca max | 5.74mm |
| ra max | 2mm |
