SKU: 31304-EU
31304 Budget Taper Roller Bearing 20x52x16.25mm
31304 Budget Taper Roller Bearing 20x52x16.25mm
Regular price
CHF 9.43
ex VAT
Regular price
Sale price
CHF 9.43
ex VAT
In stock
Price Break
10+
CHF 8.39
19+
CHF 7.92
29+
CHF 7.83
39+
CHF 7.73
49+
CHF 7.64
74+
CHF 7.54
99+
CHF 7.07
199+
CHF 6.98
249+
CHF 6.88
499+
CHF 6.79
999+
CHF 6.60
Couldn't load pickup availability
Description
Description
|
Taper Roller Bearings: Designed to carry heavy radial loads and single direction thrust loads. Supplied as a two part set consisting of the cone inner part where the rollers and cage are located and the outer cup part. |
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 20mm
- Outside Diameter:
- 52mm
- Width:
- 16.25mm
- Seals / Shields:
- None
Technical
Technical
| d | 20mm |
|---|---|
| D | 52mm |
| T | 16.25mm |
| a | 16mm |
| B | 15mm |
| C | 11mm |
| Ca min | 3mm |
| Cb min | 5mm |
| Da max | 45mm |
| Da min | 40mm |
| Db min | 48mm |
| d1 | 37.3mm |
| da max | 27mm |
| db min | 27mm |
| r1, 2 min | 1.5mm |
| r3, 4 min | 1.5 mm |
| ra max | 1.5mm |
| rb max | 1.5mm |
| Cr | 30500 N |
| C0r | 29500 N |
| e | 0.73 |
| Y | 0.82 |
| Y0 | 0.45 |
| Cur | 3350 N |
| nG | 14900 1/min |
| nB | 8400 1/min |
| kg | 0.174 kg |
