KOYO 32006JRRS Narrow Section Steering Head Set Taper Roller Bearing 30x55x17mm SEALED MODEL
KOYO 32006JRRS Narrow Section Steering Head Set Taper Roller Bearing 30x55x17mm SEALED MODEL
Regular price
CHF 30.00
ex VAT
Regular price
Sale price
CHF 30.00
ex VAT
In stock
Price Break
10+
CHF 23.24
20+
CHF 21.93
30+
CHF 21.67
40+
CHF 21.41
50+
CHF 21.15
75+
CHF 20.89
100+
CHF 19.58
200+
CHF 19.32
250+
CHF 19.06
500+
CHF 18.80
1000+
CHF 18.28
Description
Description
|
Narrow Section Taper Roller Bearings: Typically used in motorcycle steering heads these bearings are manufactured with large bore to outside diameter ratios and low overall height to permit use in space restricted applications, typically in motorcycle and automotive installations Benefits: Narrow section, low height, large bore to diameter ratio |
- Brand / Quality:
- Koyo - High Quality
- Inside Diameter:
- 30mm
- Outside Diameter:
- 55mm
- Width:
- 17/19mm
- Seals / Shields:
- Rubber Sealed
Technical
Technical
| d | 30mm |
|---|---|
| D | 55mm |
| T | 17mm |
| B | 17mm |
| C | 13mm |
| r min | 1mm |
| r1 min | 1mm |
| Dynamic load Cr | 38.2 kN |
| Static load Cor | 48 kN |
| Speed in grease | 7000 rpm |
| Speed in oil | 9400 rpm |
| a | 13.6mm |
| da min | 35.5mm |
| db max | 35mm |
| Da max | 49.5mm |
| Da min | 47mm |
| Db min | 52mm |
| Ca min | 3mm |
| Cb min | 4mm |
| ra max | 1mm |
| rb max | 1mm |
| e | 0.43 |
| Y1 | 1.39 |
| Y0 | 0.77 |
| Mass | 0.177 kg |
