SKU: 3211A-2Z/C3MT33-SKF

SKF 3211A2ZC3MT33 Double Row Angular Contact Ball Bearing with 2 Metal Shields 55x100x33.3mm

Name: SKF 3211A2ZC3MT33 Double Row Angular Contact Ball Bearing with 2 Metal Shields 55x100x33.3mm
Brand: SKF
SKU: 3211A-2Z/C3MT33-SKF
Price: 153.00 CHF
Availability: InStock

CHF 153.00 ex VAT

Sale Sold out

Equivalent to: 5211

In stock

Price Break

4+ CHF 121.65

8+ CHF 114.81

12+ CHF 113.45

16+ CHF 112.08

25+ CHF 110.71

50+ CHF 109.35

99+ CHF 102.51

199+ CHF 101.15

249+ CHF 99.78

499+ CHF 98.41

999+ CHF 95.68

Request Quotation

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More

Description

SKF Metal Shielded Double Row Angular Contact Ball Bearings: Correspond to the design of two single row angular contact ball bearings side by side but occupying less space. They can accommodate radial loads as well as axial loads acting in both directions. They provide a rigid bearing arrangement and accommodate tilting moments well.
Benefits: Compact, rigid, accommodates tilting, radial and axial loads

Equivalent: 5211

Brand / Quality:: SKF - High Quality
Inside Diameter:: 55mm
Outside Diameter:: 100mm
Width:: 33.3mm
Seals / Shields:: None
Clearance:: C3

Technical

d	55mm
D	100mm
B	33.3mm
Dynamic load Cr	60 kN
Static load Cor	47.5 kN
Fatigue load limit Pu	2 kN
Max speed	6300 rpm
Weight	0.91 kg
d1	63.2mm
D1	92.3mm
r1r2 min	1.5mm
a	57mm
da min	63mm
da max	63mm
Da max	91mm
ra max	1.5mm
