SKF 3212A2ZMT33 Double Row Angular Contact Ball Bearing with 2 Metal Shields 60x110x36.5mm

Name: SKF 3212A2ZMT33 Double Row Angular Contact Ball Bearing with 2 Metal Shields 60x110x36.5mm
Brand: SKF
SKU: 3212A-2Z/MT33-SKF
Price: 186.00 CHF
Availability: InStock

CHF 186.00 ex VAT

Sale Sold out

Equivalent to: 5212

In stock

Price Break

4+ CHF 147.99

8+ CHF 139.68

12+ CHF 138.01

16+ CHF 136.35

25+ CHF 134.69

50+ CHF 133.03

99+ CHF 124.71

199+ CHF 123.05

249+ CHF 121.39

499+ CHF 119.72

999+ CHF 116.40

Request Quotation

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More

Description

SKF Metal Shielded Double Row Angular Contact Ball Bearings: Correspond to the design of two single row angular contact ball bearings side by side but occupying less space. They can accommodate radial loads as well as axial loads acting in both directions. They provide a rigid bearing arrangement and accommodate tilting moments well.
Benefits: Compact, rigid, accommodates tilting, radial and axial loads

Equivalent: 5212

Brand / Quality:: SKF - High Quality
Inside Diameter:: 60mm
Outside Diameter:: 110mm
Width:: 36.5mm
Seals / Shields:: Metal Shielded
Clearance:: * Standard

Technical

d	60mm
D	110mm
B	36.5mm
Dynamic load Cr	73.5 kN
Static load Cor	58.5 kN
Fatigue load limit Pu	2.5 kN
Max speed	5600 rpm
Weight	1.2 kg
d1	68.8mm
D1	101mm
r1r2 min	1.5mm
a	63mm
da min	68.5mm
da max	68.5mm
Da max	101mm
ra max	1.5mm
