SKU: 32220-TIM
Timken 32220 Metric Taper Roller Bearing 100x180x49mm
Timken 32220 Metric Taper Roller Bearing 100x180x49mm
Regular price
CHF 114.59
ex VAT
Regular price
Sale price
CHF 114.59
ex VAT
In stock
Price Break
10+
CHF 101.99
19+
CHF 96.26
29+
CHF 95.11
39+
CHF 93.96
49+
CHF 92.82
74+
CHF 91.67
99+
CHF 85.94
199+
CHF 84.80
249+
CHF 83.65
499+
CHF 82.50
999+
CHF 80.21
Couldn't load pickup availability
Description
Description
|
Metric Taper Roller Bearings: These bearings have tapered inner and outer raceways between which tapered roller are arranged. The design of taper rollers makes them particularly suited to accommodating combined axial and radial loads. They are supplied as a cup and cone set (inner and outer). Benefits: Used widely in transmissions, can be used in oil or greased, high radial and axial load |
- Brand / Quality:
- Timken - High Quality
- Inside Diameter:
- 100mm
- Outside Diameter:
- 180mm
- Width:
- 49mm
Technical
Technical
| d | 100mm |
|---|---|
| D | 180mm |
| T | 49mm |
| Dynamic load | 319 kN |
| Static load | 440 kN |
| Fatigue load limit Pu | 48 kN |
| Reference speed | 2600 rpm |
| Limiting speed | 3600 rpm |
| Mass | 4.9 kg |
| d1 | 135mm |
| B | 46mm |
| C | 39mm |
| r1r2 min | 3mm |
| r3r4 min | 2.5mm |
| a | 41mm |
| da max | 115mm |
| db min | 112mm |
| Da min | 154mm |
| Da max | 168mm |
| Db min | 171mm |
| Ca min | 5mm |
| Cb min | 10mm |
| ra max | 2.5mm |
| rb max | 2mm |
| e | 0.43 |
| Y | 1.4 |
| Y0 | 0.8 |
