SKU: 32315J2-SKF
SKF 32315J2 Metric Single Row Taper Roller Bearing 75x160x58mm
SKF 32315J2 Metric Single Row Taper Roller Bearing 75x160x58mm
Regular price
CHF 262.00
ex VAT
Regular price
Sale price
CHF 262.00
ex VAT
In stock
Price Break
10+
CHF 208.45
19+
CHF 196.74
29+
CHF 194.40
39+
CHF 192.06
49+
CHF 189.71
74+
CHF 187.37
99+
CHF 175.66
199+
CHF 173.32
249+
CHF 170.98
499+
CHF 168.64
999+
CHF 163.95
Description
Description
|
SKF Taper Roller Bearings: These bearings have tapered inner and outer raceways between which tapered roller are arranged. The design of taper rollers makes them particularly suited to accommodating combined axial and radial loads. They are supplied as a cup and cone set (inner and outer). Benefits: Used widely in transmissions, can be used in oil or greased, high radial and axial load |
- Brand / Quality:
- SKF - High Quality
- Inside Diameter:
- 75mm
- Outside Diameter:
- 160mm
- Width:
- 58mm
- Seals / Shields:
- None
Technical
Technical
| d | 75mm |
|---|---|
| D | 160mm |
| T | 58mm |
| Dynamic load | 336 kN |
| Static load | 440 kN |
| Fatigue load limit Pu | 51 kN |
| Reference speed | 3000 rpm |
| Limiting speed | 4300 rpm |
| Weight | 5.2 kg |
| d1 | 113mm |
| B | 55mm |
| C | 45mm |
| r1r2 min | 3mm |
| r3r4 min | 2.5mm |
| a | 38mm |
| da max | 92mm |
| db min | 87mm |
| Da min | 133mm |
| Da max | 148mm |
| Db min | 149mm |
| Ca min | 7mm |
| Cb min | 13mm |
| ra max | 2.5mm |
| rb max | 2mm |
| Calculation factor e | 0.35 |
| Calculation factor Y | 1.7 |
| Calculation factor Y0 | 0.9 |
