SKU: 32317J2-SKF
SKF 32317J2 Metric Single Row Taper Roller Bearing 85x180x63.5mm
SKF 32317J2 Metric Single Row Taper Roller Bearing 85x180x63.5mm
Regular price
CHF 422.00
ex VAT
Regular price
Sale price
CHF 422.00
ex VAT
In stock
Price Break
10+
CHF 335.81
19+
CHF 316.95
29+
CHF 313.18
39+
CHF 309.40
49+
CHF 305.63
74+
CHF 301.86
99+
CHF 282.99
199+
CHF 279.22
249+
CHF 275.44
499+
CHF 271.67
999+
CHF 264.12
Description
Description
|
SKF Taper Roller Bearings: These bearings have tapered inner and outer raceways between which tapered roller are arranged. The design of taper rollers makes them particularly suited to accommodating combined axial and radial loads. They are supplied as a cup and cone set (inner and outer). Benefits: Used widely in transmissions, can be used in oil or greased, high radial and axial load |
- Brand / Quality:
- SKF - High Quality
- Inside Diameter:
- 85mm
- Outside Diameter:
- 180mm
- Width:
- 63.5mm
- Seals / Shields:
- None
Technical
Technical
| d | 85mm |
|---|---|
| D | 180mm |
| T | 63.5mm |
| Dynamic load | 402 kN |
| Static load | 530 kN |
| Fatigue load limit Pu | 60 kN |
| Reference speed | 2800 rpm |
| Limiting speed | 4000 rpm |
| Weight | 6.85 kg |
| d1 | 126mm |
| B | 60mm |
| C | 49mm |
| r1r2 min | 4mm |
| r3r4 min | 3mm |
| a | 42mm |
| da max | 103mm |
| db min | 99mm |
| Da min | 150mm |
| Da max | 166mm |
| Db min | 167mm |
| Ca min | 7mm |
| Cb min | 14.5mm |
| ra max | 3mm |
| rb max | 2.5mm |
| Calculation factor e | 0.35 |
| Calculation factor Y | 1.7 |
| Calculation factor Y0 | 0.9 |
