SKU: 33113-TIM
Timken 33113 Metric Taper Roller Bearing 65x110x34mm
Timken 33113 Metric Taper Roller Bearing 65x110x34mm
Regular price
CHF 134.43
ex VAT
Regular price
Sale price
CHF 134.43
ex VAT
In stock
Price Break
10+
CHF 119.64
19+
CHF 112.92
29+
CHF 111.58
39+
CHF 110.23
49+
CHF 108.89
74+
CHF 107.54
99+
CHF 100.82
199+
CHF 99.48
249+
CHF 98.13
499+
CHF 96.79
999+
CHF 94.10
Couldn't load pickup availability
Description
Description
|
Metric Taper Roller Bearings: These bearings have tapered inner and outer raceways between which tapered roller are arranged. The design of taper rollers makes them particularly suited to accommodating combined axial and radial loads. They are supplied as a cup and cone set (inner and outer). Benefits: Used widely in transmissions, can be used in oil or greased, high radial and axial load |
- Brand / Quality:
- Timken - High Quality
- Inside Diameter:
- 65mm
- Outside Diameter:
- 110mm
- Width:
- 34mm
Technical
Technical
| d | 65mm |
|---|---|
| D | 110mm |
| T | 34mm |
| Dynamic load | 142 kN |
| Static load | 208 kN |
| Fatigue load limit Pu | 24 kN |
| Reference speed | 4300 rpm |
| Limiting speed | 5600 rpm |
| Mass | 1.3 kg |
| d1 | 87.9mm |
| B | 34mm |
| C | 26.5mm |
| r1r2 min | 1.5mm |
| r3r4 min | 1.5mm |
| a | 26mm |
| da max | 74mm |
| db min | 72mm |
| Da min | 96mm |
| Da max | 103mm |
| Db min | 106mm |
| Ca min | 6mm |
| Cb min | 7.5mm |
| ra max | 1.5mm |
| rb max | 1.5mm |
| e | 0.4 |
| Y | 1.5 |
| Y0 | 0.8 |
