Timken 33220 Metric Taper Roller Bearing 100x180x63mm
Timken 33220 Metric Taper Roller Bearing 100x180x63mm
Regular price
CHF 607.00
ex VAT
Regular price
Sale price
CHF 607.00
ex VAT
In stock
Price Break
10+
CHF 482.97
20+
CHF 455.84
30+
CHF 450.41
40+
CHF 444.99
50+
CHF 439.56
75+
CHF 434.13
100+
CHF 407.00
200+
CHF 401.57
250+
CHF 396.15
500+
CHF 390.72
1000+
CHF 379.87
Share this product
Description
Description
|
Metric Taper Roller Bearings: These bearings have tapered inner and outer raceways between which tapered roller are arranged. The design of taper rollers makes them particularly suited to accommodating combined axial and radial loads. They are supplied as a cup and cone set (inner and outer). Benefits: Used widely in transmissions, can be used in oil or greased, high radial and axial load |
- Brand / Quality:
- Timken - High Quality
- Inside Diameter:
- 100mm
- Outside Diameter:
- 180mm
- Width:
- 63mm
Technical
Technical
| d | 100mm |
|---|---|
| D | 180mm |
| T | 63mm |
| Dynamic load | 429 kN |
| Static load | 655 kN |
| Fatigue load limit Pu | 71 kN |
| Reference speed | 2400 rpm |
| Limiting speed | 3600 rpm |
| Mass | 6.95 kg |
| d1 | 139mm |
| B | 63mm |
| C | 48mm |
| r1r2 min | 3mm |
| r3r4 min | 2.5mm |
| a | 43mm |
| da max | 112mm |
| db min | 112mm |
| Da min | 151mm |
| Da max | 168mm |
| Db min | 172mm |
| Ca min | 10mm |
| Cb min | 15mm |
| ra max | 2.5mm |
| rb max | 2mm |
| e | 0.4 |
| Y | 1.5 |
| Y0 | 0.8 |
