SKU: 5/16x3/4-UNF-SET36

5/16x3/4 UNF Bright Zinc Plated Set Screw

Name: 5/16x3/4 UNF Bright Zinc Plated Set Screw
Brand: Gen
SKU: 5/16x3/4-UNF-SET36
Price: 1.00 CHF
Availability: InStock

CHF 1.00 ex VAT

Sale Sold out

In stock

Price Break

10+ CHF 0.47

20+ CHF 0.36

50+ CHF 0.26

100+ CHF 0.21

500+ CHF 0.17

1000+ CHF 0.13

Request Quotation

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More

Description

Set Screw: A set screw is a type of screw generally used to secure an object within or against another object. The most common examples are securing a pulley or gear to a shaft.

Brand / Quality:: EU Budget - Economy Quality
Thread Size:: 5/16x3/4 UNF
Width of Head:: 12.45mm = 0.49 inch approx.
Depth of Head:: 5.08mm = 0.2 inch approx.
Pitch:: 24 (TPI)

Technical

Width of head (a)	12.45mm = 0.49 inch approx.
Depth of head (d)	5.08mm = 0.2 inch approx.
Head to screw (D)	19.05mm = 0.75 (3/4) inch
Overall length (d+D)	Thread diameter (f)
7.93mm = 0.312 (5/16) inch	TPI (Threads Per Inch)
24 TPI	N/A
