• SKF 51207 Single Thrust Ball Bearing 35x62x18mm
1 1

SKU: 51207-SKF

SKF 51207 Single Thrust Ball Bearing 35x62x18mm

SKF 51207 Single Thrust Ball Bearing 35x62x18mm
CHF 35.00 ex VAT
CHF 35.00 ex VAT
Sale Sold out

In stock

Price Break
10+ CHF 27.81
19+ CHF 26.25
29+ CHF 25.94
39+ CHF 25.62
49+ CHF 25.31
74+ CHF 25.00
99+ CHF 23.44
199+ CHF 23.12
249+ CHF 22.81
499+ CHF 22.50
999+ CHF 21.87
Request Quotation

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
SKF Thrust Ball Thrust Bearings: These bearings consist of three parts, a shaft and housing washer that have annular grooves in them and a caged ball bearing assembly that is sandwiched in between them. Assembly and mounting is a simple operation as the parts are separate. They support axial loads in one direction. Clearance is provided in the bore of one of the raceways to allow for alignment.
Benefits: Axial loading, ease of mounting and assembly
Brand / Quality:
SKF - High Quality
Inside Diameter:
35mm
Outside Diameter:
62mm
Width:
18mm
Technical
d 35mm
D 62mm
H 18mm
Dynamic load C 35.1 kN
Static load Co 73.5 kN
Fatigue load limit Pu 2.7 kN
Minimum load factor A 0.028
Reference speed 4000 rpm
Limiting speed 5600 rpm
Weight 0.22 kg
d1 62mm
D1 37mm
r1r2 min 1mm
da min 51mm
Da max 46mm
ra max 1mm
