• SKF 53202 Single Thrust Ball Bearing with Spherical Housing Seat U202 15x32x15mm
1 1

SKU: 53202?SKF

SKF 53202 Single Thrust Ball Bearing with Spherical Housing Seat U202 15x32x15mm

SKF 53202 Single Thrust Ball Bearing with Spherical Housing Seat U202 15x32x15mm
CHF 58.00 ex VAT
CHF 58.00 ex VAT
Sale Sold out

In stock

Price Break
10+ CHF 45.48
19+ CHF 42.93
29+ CHF 42.42
39+ CHF 41.91
49+ CHF 41.39
74+ CHF 40.88
99+ CHF 38.33
199+ CHF 37.82
249+ CHF 37.31
499+ CHF 36.79
999+ CHF 35.77
Request Quotation

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
SKF Thrust Ball Thrust Bearings Spherical Seat Type: These bearings consist of three parts, a shaft and housing washer that have annular grooves in them and a caged ball bearing assembly that is sandwiched in between them. The lower washer has a spherical face to be used with a spherical housing washer. (shown but available separately). Assembly and mounting is a simple operation as the parts are separate. They support axial loads in one direction. Clearance is provided in the bore of one of the raceways to allow for alignment.
Benefits: Axial loading, ease of mounting and assembly
Brand / Quality:
SKF - High Quality
Inside Diameter:
15mm
Outside Diameter:
32mm
Width:
15mm
Technical
d 15mm
D 32mm
H1 15mm
Dynamic load C 16.5 kN
Static load Co 27 kN
Fatigue load limit Pu 1 kN
Minimum load factor A 0.0038
Reference speed 7000 rpm
Limiting speed 10000 rpm
Weight 0.063 kg
Seating washer U202
d1 32mm
D1 17mm
D2 24mm
D3 35mm
H 13.3mm
C 4mm
R 28mm
s 12mm
r1r2 min 0.6mm
da max 25mm
Da max 24mm
ra max 0.6mm
