SKF 53212 Single Thrust Ball Bearing with Spherical Housing Seat U212 60x95x31mm
SKF 53212 Single Thrust Ball Bearing with Spherical Housing Seat U212 60x95x31mm
Regular price
CHF 194.27
ex VAT
Regular price
Sale price
CHF 194.27
ex VAT
In stock
Price Break
10+
CHF 172.90
19+
CHF 163.19
29+
CHF 161.24
39+
CHF 159.30
49+
CHF 157.36
74+
CHF 155.42
99+
CHF 145.70
199+
CHF 143.76
249+
CHF 141.82
499+
CHF 139.87
999+
CHF 135.99
Couldn't load pickup availability
Description
Description
|
SKF Thrust Ball Thrust Bearings Spherical Seat Type: These bearings consist of three parts, a shaft and housing washer that have annular grooves in them and a caged ball bearing assembly that is sandwiched in between them. The lower washer has a spherical face to be used with a spherical housing washer. (shown but available separately). Assembly and mounting is a simple operation as the parts are separate. They support axial loads in one direction. Clearance is provided in the bore of one of the raceways to allow for alignment. Benefits: Axial loading, ease of mounting and assembly |
- Brand / Quality:
- SKF - High Quality
- Inside Diameter:
- 60mm
- Outside Diameter:
- 95mm
- Width:
- 31mm
Technical
Technical
| d | 60mm |
|---|---|
| D | 95mm |
| H1 | 31mm |
| Dynamic load C | 62.4 kN |
| Static load Co | 150 kN |
| Fatigue load limit Pu | 5.6 kN |
| Minimum load factor A | 0.12 |
| Reference speed | 2800 rpm |
| Limiting speed | 3800 rpm |
| Weight | 0.82 kg |
| Seating washer | U212 |
| d1 | 95mm |
| D1 | 62mm |
| D2 | 78mm |
| D3 | 100mm |
| H | 28.02mm |
| C | 9mm |
| R | 72mm |
| s | 32.5mm |
| r1r2 min | 1mm |
| da max | 81mm |
| Da max | 78mm |
| ra max | 1mm |
