SKF 53214 Single Thrust Ball Bearing with Spherical Housing Seat U214 70x105x32mm
SKF 53214 Single Thrust Ball Bearing with Spherical Housing Seat U214 70x105x32mm
Regular price
CHF 205.32
ex VAT
Regular price
Sale price
CHF 205.32
ex VAT
In stock
Price Break
10+
CHF 182.73
19+
CHF 172.47
29+
CHF 170.42
39+
CHF 168.36
49+
CHF 166.31
74+
CHF 164.26
99+
CHF 153.99
199+
CHF 151.94
249+
CHF 149.88
499+
CHF 147.83
999+
CHF 143.72
Couldn't load pickup availability
Description
Description
|
SKF Thrust Ball Thrust Bearings Spherical Seat Type: These bearings consist of three parts, a shaft and housing washer that have annular grooves in them and a caged ball bearing assembly that is sandwiched in between them. The lower washer has a spherical face to be used with a spherical housing washer. (shown but available separately). Assembly and mounting is a simple operation as the parts are separate. They support axial loads in one direction. Clearance is provided in the bore of one of the raceways to allow for alignment. Benefits: Axial loading, ease of mounting and assembly |
- Brand / Quality:
- SKF - High Quality
- Inside Diameter:
- 70mm
- Outside Diameter:
- 105mm
- Width:
- 32mm
Technical
Technical
| d | 70mm |
|---|---|
| D | 105mm |
| H1 | 32mm |
| Dynamic load C | 65 kN |
| Static load Co | 173 kN |
| Fatigue load limit Pu | 6.4 kN |
| Minimum load factor A | 0.16 |
| Reference speed | 2600 rpm |
| Limiting speed | 3600 rpm |
| Weight | 0.97 kg |
| Seating washer | U214 |
| d1 | 105mm |
| D1 | 72mm |
| D2 | 88mm |
| D3 | 110mm |
| H | 28.8mm |
| C | 9mm |
| R | 80mm |
| s | 38mm |
| r1r2 min | 1mm |
| da max | 91mm |
| Da max | 88mm |
| ra max | 1mm |
