• 53226 Budget Single Thrust Ball Bearing with Spherical Housing Seat U226 130x190x53mm
1 1

SKU: 53226?EU

53226 Budget Single Thrust Ball Bearing with Spherical Housing Seat U226 130x190x53mm

53226 Budget Single Thrust Ball Bearing with Spherical Housing Seat U226 130x190x53mm
CHF 411.00 ex VAT
CHF 411.00 ex VAT
Sale Sold out

In stock

Price Break
10+ CHF 327.02
19+ CHF 308.65
29+ CHF 304.98
39+ CHF 301.30
49+ CHF 297.63
74+ CHF 293.95
99+ CHF 275.58
199+ CHF 271.91
249+ CHF 268.23
499+ CHF 264.56
999+ CHF 257.21
Request Quotation

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Thrust Ball Thrust Bearings Spherical Seat Type: These bearings consist of three parts, a shaft and housing washer that have annular grooves in them and a caged ball bearing assembly that is sandwiched in between them. The lower washer has a spherical face to be used with a spherical housing washer. Assembly and mounting is a simple operation as the parts are separate. They support axial loads in one direction. Clearance is provided in the bore of one of the raceways to allow for alignment.
Benefits: Axial loading, ease of mounting and assembly
Brand / Quality:
EU Budget - Economy Quality
Inside Diameter:
130mm
Outside Diameter:
190mm
Width:
53mm
Technical
d 130mm
D 190mm
H1 53mm
Dynamic load C 186 kN
Static load Co 585 kN
Fatigue load limit Pu 17 kN
Minimum load factor A 1.8
Reference speed 1400 rpm
Limiting Speed 2000 rpm
Weight 4.85 kg
Seating Washer U226
d1 187mm
D1 133mm
D2 160mm
D3 195mm
H 47.9mm
C 17mm
R 140mm
s 67mm
r1r2 min 1.5mm
da max 166mm
Da max 160mm
ra max 1.5mm
