SKU: 53312?SKF

SKF 53312 Single Thrust Ball Bearing with Spherical Housing Seat U312 60x110x42mm

Name: SKF 53312 Single Thrust Ball Bearing with Spherical Housing Seat U312 60x110x42mm
Brand: SKF
SKU: 53312?SKF
Price: 283.00 CHF
Availability: InStock

CHF 283.00 ex VAT

Sale Sold out

In stock

Price Break

10+ CHF 225.25

19+ CHF 212.60

29+ CHF 210.07

39+ CHF 207.54

49+ CHF 205.01

74+ CHF 202.48

99+ CHF 189.82

199+ CHF 187.29

249+ CHF 184.76

499+ CHF 182.23

999+ CHF 177.17

Request Quotation

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More

Description

SKF Thrust Ball Thrust Bearings Spherical Seat Type: These bearings consist of three parts, a shaft and housing washer that have annular grooves in them and a caged ball bearing assembly that is sandwiched in between them. The lower washer has a spherical face to be used with a spherical housing washer. (shown but available separately). Assembly and mounting is a simple operation as the parts are separate. They support axial loads in one direction. Clearance is provided in the bore of one of the raceways to allow for alignment.
Benefits: Axial loading, ease of mounting and assembly

Brand / Quality:: SKF - High Quality
Inside Diameter:: 60mm
Outside Diameter:: 110mm
Width:: 42mm

Technical

d	60mm
D	110mm
H1	42mm
Dynamic load C	101 kN
Static load Co	224 kN
Fatigue load limit Pu	8.3 kN
Minimum load factor A	0.26
Reference speed	2200 rpm
Limiting speed	3000 rpm
Weight	1.71 kg
Seating washer	U312
d1	110mm
D1	62mm
D2	85mm
D3	115mm
H	38.3mm
C	11.5mm
R	90mm
s	41mm
r1r2 min	1.1mm
da max	90mm
Da max	85mm
ra max	1mm
