SKU: 53410?SKF
SKF 53410 Single Thrust Ball Bearing with Spherical Housing Seat U410 50x110x50mm
SKF 53410 Single Thrust Ball Bearing with Spherical Housing Seat U410 50x110x50mm
Regular price
CHF 452.63
ex VAT
Regular price
Sale price
CHF 452.63
ex VAT
In stock
Price Break
10+
CHF 402.84
19+
CHF 380.21
29+
CHF 375.68
39+
CHF 371.16
49+
CHF 366.63
74+
CHF 362.10
99+
CHF 339.47
199+
CHF 334.95
249+
CHF 330.42
499+
CHF 325.89
999+
CHF 316.84
Couldn't load pickup availability
Description
Description
|
SKF Thrust Ball Thrust Bearings Spherical Seat Type: These bearings consist of three parts, a shaft and housing washer that have annular grooves in them and a caged ball bearing assembly that is sandwiched in between them. The lower washer has a spherical face to be used with a spherical housing washer. (shown but available separately). Assembly and mounting is a simple operation as the parts are separate. They support axial loads in one direction. Clearance is provided in the bore of one of the raceways to allow for alignment. Benefits: Axial loading, ease of mounting and assembly |
- Brand / Quality:
- SKF - High Quality
- Inside Diameter:
- 50mm
- Outside Diameter:
- 110mm
- Width:
- 50mm
Technical
Technical
| d | 50mm |
|---|---|
| D | 110mm |
| H1 | 50mm |
| Dynamic load C | 159 kN |
| Static load Co | 340 kN |
| Fatigue load limit Pu | 12.5 kN |
| Minimum load factor A | 0.6 |
| Reference speed | 2000 rpm |
| Limiting speed | 2800 rpm |
| Weight | 2.31 kg |
| Seating washer | U410 |
| d1 | 110mm |
| D1 | 52mm |
| D2 | 80mm |
| D3 | 115mm |
| H | 45.6mm |
| C | 14mm |
| R | 90mm |
| s | 35mm |
| r1r2 min | 1.5mm |
| da max | 86mm |
| Da max | 80mm |
| ra max | 1.5mm |
