SKU: 6012NR/C4-SKF
SKF 6012NRC4 Open Type Snap Ring Deep Groove Bearing 60x95x18mm
SKF 6012NRC4 Open Type Snap Ring Deep Groove Bearing 60x95x18mm
Regular price
CHF 132.43
ex VAT
Regular price
Sale price
CHF 132.43
ex VAT
In stock
Price Break
10+
CHF 117.86
19+
CHF 111.24
29+
CHF 109.92
39+
CHF 108.59
49+
CHF 107.27
74+
CHF 105.94
99+
CHF 99.32
199+
CHF 98.00
249+
CHF 96.67
499+
CHF 95.35
999+
CHF 92.70
Couldn't load pickup availability
Description
Description
|
Deep Groove Ball Bearings with Snap Ring: A popular choice where the housings is part of a machine frame casing, these bearing types are manufactured without seals to allow the circulation of the oil or grease lubricant. The snap ring is made from a spring steel material and fits into an annular groove around the outside of the bearing which is offset to one side. |
- Brand / Quality:
- SKF - High Quality
- Inside Diameter:
- 60mm
- Outside Diameter:
- 95mm
- Width:
- 18mm
- Seals / Shields:
- None
- Clearance:
- C4
- Snap Ring:
- Snap Ring
Technical
Technical
| d | 60mm |
|---|---|
| D | 95mm |
| B | 18mm |
| Dynamic load C | 30.7 kN |
| Static load Co | 23.2 kN |
| Fatigue load limit Pu | 0.98 kN |
| Reference speed | 15000 rpm |
| Limiting speed | 9500 rpm |
| Weight | 0.4kg |
| Snap ring | SP 95 |
| d1 | 71.3mm |
| D2 | 86.5mm |
| D3 | 91.82mm |
| D4 | 101.6mm |
| b | 2.7mm |
| f | 2.46mm |
| C | 2.87mm |
| r1r2 min | 1.1mm |
| ro max | 0.6mm |
| da min | 66mm |
| Da max | 89mm |
| Db min | 103mm |
| ba min | 3mm |
| Ca max | 5.33mm |
| ra max | 1mm |
| Calc Factor kr | 0.025 |
| fo | 16 |
