SKU: 6020-2RS-CDX
Codex 60202RS Rubber Sealed Deep Groove Ball Bearing 100x150x24mm
Codex 60202RS Rubber Sealed Deep Groove Ball Bearing 100x150x24mm
Regular price
CHF 56.73
ex VAT
Regular price
Sale price
CHF 56.73
ex VAT
Equivalent to: 60202RS 60202RSH 60202RS1 60202RSR 60202RSL 6020LFS 6020EE 6020DU 6020LLU EL1002RS 6020PP 9120PP 120KSZZ
In stock
Price Break
10+
CHF 50.49
19+
CHF 47.65
29+
CHF 47.09
39+
CHF 46.52
49+
CHF 45.95
74+
CHF 45.38
99+
CHF 42.55
199+
CHF 41.98
249+
CHF 41.41
499+
CHF 40.85
999+
CHF 39.71
Couldn't load pickup availability
Description
Description
|
Rubber Sealed Deep Groove Ball Bearings: One of the most commonly used bearings, these types are manufactured with rubber seals inserted into the outer raceway and in contact with the inner race providing protection against the ingress of moisture, dust and other foreign matter and serve to retain the pre-filled grease in the bearing |
Equivalent: 60202RS 60202RSH 60202RS1 60202RSR 60202RSL 6020LFS 6020EE 6020DU 6020LLU EL1002RS 6020PP 9120PP 120KSZZ
- Brand / Quality:
- Codex - Good Quality
- Inside Diameter:
- 100mm
- Outside Diameter:
- 150mm
- Width:
- 24mm
- Seals / Shields:
- Rubber Sealed
- Clearance:
- * Standard
Technical
Technical
| d | 100mm |
|---|---|
| D | 150mm |
| B | 24mm |
| Dynamic load C | 63.7 kN |
| Static load Co | 54 kN |
| Fatigue load limit Pu | 2.04 |
| Reference speed | 9500 rpm |
| Limiting speed | 2600 rpm |
| Weight | 1.25 kg |
| d1 | -mm |
| D2 | 138mm |
| r1r2 | 1.5mm |
| da min | 107mm |
| Da max | 143mm |
| ra max | 1.5mm |
| Calc factor kr | 0.025 |
| Calc factor Cor f0 | 16 |
