SKU: 6203/VA201-SKF

SKF 6203VA201 Single Row Deep Groove Ball Bearing High Temperature Type 17x40x12mm

Name: SKF 6203VA201 Single Row Deep Groove Ball Bearing High Temperature Type 17x40x12mm
Brand: SKF
SKU: 6203/VA201-SKF
Price: 32.00 CHF
Availability: InStock

CHF 32.00 ex VAT

Sale Sold out

In stock

Price Break

10+ CHF 25.02

19+ CHF 23.61

29+ CHF 23.33

39+ CHF 23.05

49+ CHF 22.77

74+ CHF 22.49

99+ CHF 21.08

199+ CHF 20.80

249+ CHF 20.52

499+ CHF 20.24

999+ CHF 19.68

Request Quotation

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More

Description

SKF VA201 Series High Temperature Bearings: Supplied as an open type bearing are designed for high temperatures up to + 250 degrees Celsius and down to - 40 degrees Celsius. At temperatures over + 200 dry lubrication pertains. Designed for speeds up to 100rpm without maintenance. Internal clearance is C5 and all have a BLACK PHOSPHATED COATING
Benefits: High temperature resilience, low maintenance

Brand / Quality:: SKF - High Quality
Inside Diameter:: 17mm
Outside Diameter:: 40mm
Width:: 12mm
Seals / Shields:: None
Clearance:: * Standard

Technical

d	17mm
D	40mm
B	12mm
d1	24.2mm
D2	35mm
r1r2	0.6mm
Basic load rating Co	4.75 kN
Weight	0.065 kg
Max operating temp	+250 deg C
Min operating temp	-40 deg C
Recommended max speed	100 rpm
