SKU: 6209/VA201-SKF
SKF 6209VA201 Single Row Deep Groove Ball Bearing High Temperature Type 45x85x19mm
SKF 6209VA201 Single Row Deep Groove Ball Bearing High Temperature Type 45x85x19mm
Regular price
CHF 61.99
ex VAT
Regular price
Sale price
CHF 61.99
ex VAT
In stock
Price Break
10+
CHF 55.17
19+
CHF 52.07
29+
CHF 51.45
39+
CHF 50.83
49+
CHF 50.21
74+
CHF 49.59
99+
CHF 46.49
199+
CHF 45.87
249+
CHF 45.25
499+
CHF 44.63
999+
CHF 43.39
Couldn't load pickup availability
Description
Description
|
SKF VA201 Series High Temperature Bearings: Supplied as an open type bearing are designed for high temperatures up to + 250 degrees Celsius and down to - 40 degrees Celsius. At temperatures over + 200 dry lubrication pertains. Designed for speeds up to 100rpm without maintenance. Internal clearance is C5 and all have a BLACK PHOSPHATED COATING Benefits: High temperature resilience, low maintenance |
- Brand / Quality:
- SKF - High Quality
- Inside Diameter:
- 45mm
- Outside Diameter:
- 85mm
- Width:
- 19mm
- Seals / Shields:
- None
- Clearance:
- * Standard
Technical
Technical
| d | 45mm |
|---|---|
| D | 85mm |
| B | 19mm |
| d1 | 57.6mm |
| D2 | 75.2mm |
| r1r2 | 1.1mm |
| Basic load rating Co | 21.6 kN |
| Weight | 0.41 kg |
| Max operating temp | +250 deg C |
| Min operating temp | -40 deg C |
| Recommended max speed | 100 rpm |
