SKU: 6309/VA201-SKF
SKF 6309VA201 Single Row Deep Groove Ball Bearing High Temperature Type 45x100x25mm
SKF 6309VA201 Single Row Deep Groove Ball Bearing High Temperature Type 45x100x25mm
Regular price
CHF 86.43
ex VAT
Regular price
Sale price
CHF 86.43
ex VAT
In stock
Price Break
10+
CHF 76.92
19+
CHF 72.60
29+
CHF 71.74
39+
CHF 70.87
49+
CHF 70.01
74+
CHF 69.14
99+
CHF 64.82
199+
CHF 63.96
249+
CHF 63.09
499+
CHF 62.23
999+
CHF 60.50
Couldn't load pickup availability
Description
Description
|
SKF VA201 Series High Temperature Bearings: Supplied as an open type bearing are designed for high temperatures up to + 250 degrees Celsius and down to - 40 degrees Celsius. At temperatures over + 200 dry lubrication pertains. Designed for speeds up to 100rpm without maintenance. Internal clearance is C5 and all have a BLACK PHOSPHATED COATING Benefits: High temperature resilience, low maintenance |
- Brand / Quality:
- SKF - High Quality
- Inside Diameter:
- 45mm
- Outside Diameter:
- 100mm
- Width:
- 25mm
- Seals / Shields:
- None
- Clearance:
- * Standard
Technical
Technical
| d | 45mm |
|---|---|
| D | 100mm |
| B | 25mm |
| d1 | 62.1mm |
| D2 | 86.7mm |
| r1r2 | 1.5mm |
| Basic load rating Co | 31.5 kN |
| Weight | 0.83 kg |
| Max operating temp | +250 deg C |
| Min operating temp | -40 deg C |
| Recommended max speed | 100 rpm |
