75AT10/1860 ContiTech Standard Synchroflex Timing Belt 75mm Width 10mm Pitch 186 Teeth
75AT10/1860 ContiTech Standard Synchroflex Timing Belt 75mm Width 10mm Pitch 186 Teeth
Regular price
CHF 320.00
ex VAT
Regular price
Sale price
CHF 320.00
ex VAT
In stock
Price Break
3+
CHF 254.31
5+
CHF 240.02
10+
CHF 237.17
15+
CHF 234.31
20+
CHF 231.45
30+
CHF 228.59
40+
CHF 214.31
50+
CHF 211.45
60+
CHF 208.59
75+
CHF 205.73
100+
CHF 200.02
Description
Description
AT Standard SYNCHROFLEX® Timing Belts: This belt is manufactured by ContiTech, specialists in rubber and plastics technology. This Synchroflex belt is a truly endless belt, suitable for AT pulleys.
Standard Synchroflex belts consist of just two components, a wear-resistant Contilan carcass and high-grade endless steel wire tension members. This construction provides high flank load capacity and low elastic elongation which makes them unsurpassed for quality and accuracy.
Benefits: High power AT profile, low elastic elongation and high flank load capacity.
- Brand / Quality:
- ContiTech - High Quality
- Thickness:
- 2.5mm
- Belt Width Approx:
- 75mm
- Belt Length Approx:
- 1860mm
- Number of Teeth:
- 186
- Item Type:
- AT10 Standard Timing Belt
Technical
Technical
| No of Teeth | 186 |
|---|---|
| Belt Width | 75mm |
| Belt Pitch | 10mm (AT10) |
| Belt Length | 1860mm |
| Belt Thickness (hs) | 2.5mm |
| Tooth Height (ht) | 2.5mm |
| Tooth Pitch (t) | 10mm |
| Flank Angle (f) | 50 deg |
| Tension Member Loadings | 12000 N |
| Belt Weight (per metre) | 0.473kg |
