SNR ESF206-19 Imperial Four Bolt Square Cast Iron Flange Housing with Eccentric Collar 1-3/16 inch Bore
SNR ESF206-19 Imperial Four Bolt Square Cast Iron Flange Housing with Eccentric Collar 1-3/16 inch Bore
Regular price
CHF 33.64
ex VAT
Regular price
Sale price
CHF 33.64
ex VAT
In stock
Price Break
10+
CHF 29.94
19+
CHF 28.26
29+
CHF 27.92
39+
CHF 27.58
49+
CHF 27.25
74+
CHF 26.91
99+
CHF 25.23
199+
CHF 24.89
249+
CHF 24.56
499+
CHF 24.22
999+
CHF 23.55
Couldn't load pickup availability
Description
Description
ESF200 Series 4 Bolt Cast Iron Square Flange Housing: These cast iron housing units include a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required.
Benefits: High tolerance to harsh environments, cost-effective bearing/housing assembly, re-lubricatable, replaceable insert, grub screw fixing
- Brand / Quality:
- SNR - High Quality
- Inside Diameter:
- 30.16mm = 1.187 (1-3/16) inch
- Style:
- ESF
- Bolt Hole Centres:
- 83mm
Technical
Technical
| --- | Dimensions |
|---|---|
| Shaft diameter d | 1-3/16 inch |
| A | 31mm |
| A1 | 13mm |
| A2 | 44.7mm |
| B | 23.8mm |
| B1 | 35.7mm |
| d1 | 44.1mm |
| e | 18mm |
| J | 83mm |
| L | 108mm |
| N | 12mm |
| S | 9mm |
| G | M6x1 |
| --- | Load rating |
| Dynamic load C | 19.5 kN |
| Static load C0 | 11.2 kN |
| --- | Unit information |
| Operating temperature min. | -20°C |
| Operating temperature max. | 100°C |
| Recommended tightening torque for set screw | 8 Nm |
| Mass | 1.1 kg |
