SKU: EXF312-SNR
SNR EXF312 Metric Four Bolt Square Cast Iron Flange Housing with 60mm Bore Eccentric Collar Insert
SNR EXF312 Metric Four Bolt Square Cast Iron Flange Housing with 60mm Bore Eccentric Collar Insert
Regular price
CHF 146.00
ex VAT
Regular price
Sale price
CHF 146.00
ex VAT
In stock
Price Break
3+
CHF 115.82
4+
CHF 109.31
9+
CHF 108.01
19+
CHF 106.71
49+
CHF 105.41
99+
CHF 104.11
499+
CHF 97.60
999+
CHF 96.30
1999+
CHF 95.00
2999+
CHF 93.69
4999+
CHF 91.09
Description
Description
|
UCF or SF Series 4 Bolt Square Cast Iron Housings: Bearing units supplied with a fully sealed bearing insert fitted in the cast iron housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing |
- Brand / Quality:
- SNR - High Quality
- Inside Diameter:
- 60mm
- Style:
- EXF
- Bolt Hole Centres:
- 150mm
Technical
Technical
| --- | Dimensions |
|---|---|
| Shaft diameter d | 60mm |
| A | 56mm |
| A1 | 22mm |
| A2 | 81.45mm |
| B | 61.9mm |
| B1 | 79.4mm |
| d1 | 89mm |
| e | 33mm |
| J | 150mm |
| L | 193mm |
| N | 23mm |
| S | 30.95mm |
| G | M6x1 |
| --- | Load rating |
| Dynamic load C | 81.6 kN |
| Static load C0 | 51.8 kN |
| --- | Unit information |
| Operating temperature min. | -20°C |
| Operating temperature max. | 100°C |
| Recommended tightening torque for set screw | 22 Nm |
| Mass | 6.62 kg |
