SKU: FC50A-RHP
RHP FC50A-RHP Four Bolt Round Cast Iron Flanged Bearing Unit and 50mm Insert
RHP FC50A-RHP Four Bolt Round Cast Iron Flanged Bearing Unit and 50mm Insert
Regular price
CHF 100.00
ex VAT
Regular price
Sale price
CHF 100.00
ex VAT
In stock
Price Break
10+
CHF 79.37
20+
CHF 74.91
30+
CHF 74.02
40+
CHF 73.13
50+
CHF 72.24
75+
CHF 71.35
100+
CHF 66.89
200+
CHF 66.00
250+
CHF 65.10
500+
CHF 64.21
1000+
CHF 62.43
Share this product
Description
Description
|
RHP FC A Series 4 Bolt Round Cast Iron Housing Units: Four bolt round cast iron bearing unit supplied with a sealed flat back bearing insert fitted and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft after installation. |
- Brand / Quality:
- RHP - High Quality
- Inside Diameter:
- 50mm
- Style:
- FC
- Pitch Circle Diameter:
- 135mm
Technical
Technical
| Bore | 50mm |
|---|---|
| L | 165mm |
| H | 110mm |
| J | 135mm |
| G | 12mm |
| A | 25mm |
| A1 | 31.52mm |
| A5 | 13mm |
| B1 | 43.5mm |
| s1 | 11.04mm |
| d1 | 62.2mm |
| Dynamic load | 35000 N |
| Static load | 23200 N |
| Rec max speed | 3400 rpm |
| Weight | 2.8 kg |
| Insert | <a href="advanced_search_result.php?keywords=1250-50AG+insonly">1250-50AG Click Here</a> |
| Casting group | 8 |
| Grease nipple thread | 1/4 UNF, 1/4 inch x 28 TPI |
