SKU: FHR-3-1/4
Major Brand FHR3-1/4 Hex Head Flanged Hi-Roller Bearing 3-1/4 inch Outside Diameter
Major Brand FHR3-1/4 Hex Head Flanged Hi-Roller Bearing 3-1/4 inch Outside Diameter
Regular price
CHF 276.00
ex VAT
Regular price
Sale price
CHF 276.00
ex VAT
Equivalent to: FHR-325-A FLR-3-1/4 FCF-3-1/4 FCR-3-1/4
In stock
Price Break
3+
CHF 218.84
4+
CHF 206.54
9+
CHF 204.08
19+
CHF 201.62
29+
CHF 199.17
39+
CHF 196.71
49+
CHF 184.41
59+
CHF 181.95
249+
CHF 179.50
499+
CHF 177.04
999+
CHF 172.12
Description
Description
|
Flanged Hi-Roller Bearing: Designed for applications where both radial and thrust loading are present. These bearings are tightly sealed with an expansion plug on one end and radial contact lip seals on the bearings. They are capable of running at much higher speeds than needle bearing cam followers. Benefits: Ideal for use in environments where dust or high moisture is present. |
Equivalent: FHR-325-A FLR-3-1/4 FCF-3-1/4 FCR-3-1/4
- Brand / Quality:
- Major Brand - High Quality
- Outside Diameter:
- 82.55mm = 3.25 (3-1/4) inch
- Width:
- 50.8mm = 2 inch
Technical
Technical
| A | 3.25 inch |
|---|---|
| B | 2 inch |
| C | 4.188 inch |
| D | 0.594 inch |
| K | 1.25 inch |
| L | 2.5 inch |
| M | 1.75 inch |
| Thread class 2A N | 1-1/4-12 UNF |
| R | 1.75 inch |
| S | 0.062 inch |
| Basic dynamic rating | 14300 lbs |
| Dynamic thrust load rating | 5790 lbs |
| Max static capacity | 20000 lbs |
