SKU: FYT25TF/VA201-SKF
SKF FYT25TFVA201 Y Bearing Two Bolt Oval High Temperature Flange Unit Housing with Steel Cage Insert for Metric Shaft 25mm
SKF FYT25TFVA201 Y Bearing Two Bolt Oval High Temperature Flange Unit Housing with Steel Cage Insert for Metric Shaft 25mm
Regular price
CHF 133.00
ex VAT
Regular price
Sale price
CHF 133.00
ex VAT
In stock
Price Break
10+
CHF 105.32
19+
CHF 99.40
29+
CHF 98.22
39+
CHF 97.03
49+
CHF 95.85
74+
CHF 94.67
99+
CHF 88.75
199+
CHF 87.57
249+
CHF 86.38
499+
CHF 85.20
999+
CHF 82.83
Share this product
Description
Description
|
SKF High Temperature Housings and Bearing Inserts: VA201 have a grey cast iron housing and have steel cages, they are lubricated with a polyalkylene glycol/graphite mixture and can be used at temperatures from -40 deg to +250 deg Celsius, at prolonged use over 200 deg Celsius dry lubricant pertains. All versions are characterised by their BLACK PHOSPHATED COATING on the inserts.They have a max rotational speed of 100 rpm Benefits:High temp tolerance from -40 to +250 deg Celsius |
- Brand / Quality:
- SKF - High Quality
- Inside Diameter:
- 25mm
- Temperature Range:
- High Temp
Technical
Technical
| d | 25mm |
|---|---|
| A1 | 30mm |
| A2 | 12mm |
| B | 34.1mm |
| H | 124mm |
| J | 98.9mm |
| L | 70mm |
| N | 12.7mm |
| G | 10mm |
| T | 38.8mm |
| Dynamic load C | 14 kN |
| Static load Co | 7.8 kN |
| Weight | 0.63 kg |
