SKU: FYTB15FM-SKF
SKF FYTB15FM Oval Cast Housing with Grub Screw 15mm Insert
SKF FYTB15FM Oval Cast Housing with Grub Screw 15mm Insert
Regular price
CHF 41.22
ex VAT
Regular price
Sale price
CHF 41.22
ex VAT
In stock
Price Break
10+
CHF 36.69
19+
CHF 34.62
29+
CHF 34.21
39+
CHF 33.80
49+
CHF 33.39
74+
CHF 32.98
99+
CHF 30.92
199+
CHF 30.50
249+
CHF 30.09
499+
CHF 29.68
999+
CHF 28.85
Couldn't load pickup availability
Description
Description
|
SKF Oval Flanged Y-bearing Units with Cast Housing and Grub Screws: These units have an oval flange and two holes for attachment bolts. A grease fitting in the housing allows the unit to be re-lubricated. This makes them especially suitable for bearing arrangements that operate under high levels of contamination, high speeds, high temperatures or relatively heavy loads. Benefits: Grease fitting allows re-lubrication |
- Brand / Quality:
- SKF - High Quality
- Inside Diameter:
- 15mm
- Style:
- FYTB
- Bolt Hole Centres:
- 76.5mm
Technical
Technical
| d | 15mm |
|---|---|
| A1 | 26mm |
| A2 | 11mm |
| B1 | 28.6mm |
| Da | 50.8mm |
| H | 98.5mm |
| J | 76.5mm |
| L | 57mm |
| N | 11.5mm |
| G | 10mm |
| s1 | 22.1mm |
| T | 39.1mm |
| Static load Cr | 4.75 kN |
| Dynamic load Cor | 9.56 kN |
| Fatigue load limit Pu | 0.2 kN |
| Limiting speed | 9500 rpm |
| Weight | 0.42 kg |
