SKU: FYTB50TF-SKF
SKF FYTB50TF Oval Cast Housing with Grub Screw 50mm Insert
SKF FYTB50TF Oval Cast Housing with Grub Screw 50mm Insert
Regular price
CHF 103.00
ex VAT
Regular price
Sale price
CHF 103.00
ex VAT
In stock
Price Break
10+
CHF 81.87
20+
CHF 77.27
30+
CHF 76.35
40+
CHF 75.43
50+
CHF 74.51
75+
CHF 73.59
100+
CHF 68.99
200+
CHF 68.07
250+
CHF 67.15
500+
CHF 66.23
1000+
CHF 64.39
Description
Description
|
SKF Oval Flanged Y-bearing Units with Cast Housing: These units have an oval flange and two holes for attachment bolts. A grease fitting in the housing allows the unit to be re-lubricated. This makes them especially suitable for bearing arrangements that operate under high levels of contamination, high speeds, high temperatures or relatively heavy loads. Benefits: Grease fitting allows re-lubrication |
- Brand / Quality:
- SKF - High Quality
- Inside Diameter:
- 50mm
- Style:
- FYTB
- Bolt Hole Centres:
- 157mm
Technical
Technical
| d | 50mm |
|---|---|
| A1 | 43mm |
| A2 | 15mm |
| B | 51.6mm |
| Da | 101.6mm |
| H | 189mm |
| J | 157mm |
| L | 116mm |
| N | 18mm |
| G | 16mm |
| s1 | 32.6mm |
| T | 60.6mm |
| Static load Cr | 23.2 kN |
| Dynamic load Cor | 35.1 kN |
| Fatigue load limit Pu | 0.98 kN |
| Limiting speed | 4000 rpm |
| A5 | 29.5mm |
| Weight | 2.15 kg |
| Compatible end cover closed | ECY210 |
