SKU: FYTJ40TF-SKF
SKF FYTJ40TF Oval Cast Housing with Grub Screw 40mm Insert
SKF FYTJ40TF Oval Cast Housing with Grub Screw 40mm Insert
Regular price
CHF 80.06
ex VAT
Regular price
Sale price
CHF 80.06
ex VAT
In stock
Price Break
10+
CHF 71.25
19+
CHF 67.25
29+
CHF 66.45
39+
CHF 65.65
49+
CHF 64.85
74+
CHF 64.05
99+
CHF 60.05
199+
CHF 59.24
249+
CHF 58.44
499+
CHF 57.64
999+
CHF 56.04
Couldn't load pickup availability
Description
Description
|
SKF Oval Flanged Y-bearing Units with Cast Housing: These units have an oval flange and two holes for attachment bolts. A grease fitting in the housing allows the unit to be re-lubricated. This makes them especially suitable for bearing arrangements that operate under high levels of contamination, high speeds, high temperatures or relatively heavy loads. Benefits: Grease fitting allows re-lubrication |
- Brand / Quality:
- SKF - High Quality
- Inside Diameter:
- 40mm
- Style:
- FYTJ
- Bolt Hole Centres:
- 144mm
Technical
Technical
| d | 40mm |
|---|---|
| A1 | 36mm |
| A2 | 16mm |
| B | 49.2mm |
| Da | 88.9mm |
| H | 175mm |
| J | 144mm |
| L | 100mm |
| N | 16mm |
| G | 14mm |
| s1 | 30.2mm |
| T | 51.2mm |
| Static load Cr | 19 kN |
| Dynamic load Cor | 30.7 kN |
| Fatigue load limit Pu | 0.8 kN |
| Limiting speed | 4800 rpm |
| Weight | 1.55 kg |
