SKU: FYTJ45KF-SKF
SKF FYTJ45KF Flanged Unit with an Oval Cast Housing with 40mm Insert
SKF FYTJ45KF Flanged Unit with an Oval Cast Housing with 40mm Insert
Regular price
CHF 102.00
ex VAT
Regular price
Sale price
CHF 102.00
ex VAT
In stock
Price Break
10+
CHF 80.87
20+
CHF 76.33
30+
CHF 75.42
40+
CHF 74.51
50+
CHF 73.60
75+
CHF 72.69
100+
CHF 68.15
200+
CHF 67.24
250+
CHF 66.33
500+
CHF 65.42
1000+
CHF 63.61
Description
Description
|
SKF Oval Flanged Y-bearing Units with Cast Housing and Adapter Sleeve: These units have an oval flange and two holes for attachment bolts. A grease fitting in the housing allows the unit to be re-lubricated. This makes them especially suitable for bearing arrangements that operate under high levels of contamination, high speeds, high temperatures or relatively heavy loads. Note: The appropriate adapter sleeve is not part of the bearing and must be ordered separately. Benefits: Grease fitting allows re-lubrication |
- Brand / Quality:
- SKF - High Quality
- Inside Diameter:
- 40mm
- Style:
- FYTJ
- Bolt Hole Centres:
- 148mm
Technical
Technical
| d | 40mm |
|---|---|
| A1 | 36mm |
| A2 | 18mm |
| B1 | 50mm |
| Da | 98.4mm |
| H | 188mm |
| J | 148mm |
| L | 108mm |
| N | 19mm |
| G | 16mm |
| s1 | 28.5mm |
| T | 50.5mm |
| Static load Cr | 21.6 kN |
| Dynamic load Cor | 33.2 kN |
| Fatigue load limit Pu | 0.915 kN |
| Limiting speed | 4300 rpm |
| Weight | 2.2 kg |
