SKU: FYTJ45TF-SKF
SKF FYTJ45TF Oval Cast Housing with Grub Screw 45mm Insert
SKF FYTJ45TF Oval Cast Housing with Grub Screw 45mm Insert
Regular price
CHF 77.93
ex VAT
Regular price
Sale price
CHF 77.93
ex VAT
In stock
Price Break
10+
CHF 69.36
19+
CHF 65.46
29+
CHF 64.68
39+
CHF 63.90
49+
CHF 63.12
74+
CHF 62.34
99+
CHF 58.45
199+
CHF 57.67
249+
CHF 56.89
499+
CHF 56.11
999+
CHF 54.55
Couldn't load pickup availability
Description
Description
|
SKF Oval Flanged Y-bearing Units with Cast Housing: These units have an oval flange and two holes for attachment bolts. A grease fitting in the housing allows the unit to be re-lubricated. This makes them especially suitable for bearing arrangements that operate under high levels of contamination, high speeds, high temperatures or relatively heavy loads. Benefits: Grease fitting allows re-lubrication |
- Brand / Quality:
- SKF - High Quality
- Inside Diameter:
- 45mm
- Style:
- FYTJ
- Bolt Hole Centres:
- 148mm
Technical
Technical
| d | 45mm |
|---|---|
| A1 | 38mm |
| A2 | 18mm |
| B | 49.2mm |
| Da | 98.4mm |
| H | 188mm |
| J | 148mm |
| L | 108mm |
| N | 19mm |
| G | 16mm |
| s1 | 30.2mm |
| T | 52.2mm |
| Static load Cr | 21.6 kN |
| Dynamic load Cor | 33.2 kN |
| Fatigue load limit Pu | 0.916 kN |
| Limiting speed | 4300 rpm |
| Weight | 2.2 kg |
