SKU: FYTJ50KF-SKF
SKF FYTJ50KF Flanged Unit with an Oval Cast Housing with 45mm Insert
SKF FYTJ50KF Flanged Unit with an Oval Cast Housing with 45mm Insert
Regular price
CHF 119.17
ex VAT
Regular price
Sale price
CHF 119.17
ex VAT
In stock
Price Break
10+
CHF 106.06
19+
CHF 100.10
29+
CHF 98.91
39+
CHF 97.72
49+
CHF 96.53
74+
CHF 95.34
99+
CHF 89.38
199+
CHF 88.19
249+
CHF 86.99
499+
CHF 85.80
999+
CHF 83.42
Couldn't load pickup availability
Description
Description
|
SKF Oval Flanged Y-bearing Units with Cast Housing and Adapter Sleeve: These units have an oval flange and two holes for attachment bolts. A grease fitting in the housing allows the unit to be re-lubricated. This makes them especially suitable for bearing arrangements that operate under high levels of contamination, high speeds, high temperatures or relatively heavy loads. Note: The appropriate adapter sleeve is not part of the bearing and must be ordered separately. Benefits: Grease fitting allows re-lubrication |
- Brand / Quality:
- SKF - High Quality
- Inside Diameter:
- 45mm
- Style:
- FYTJ
- Bolt Hole Centres:
- 157mm
Technical
Technical
| d | 45mm |
|---|---|
| A1 | 40mm |
| A2 | 18mm |
| B1 | 55mm |
| Da | 101.6mm |
| H | 195mm |
| J | 157mm |
| L | 115mm |
| N | 19mm |
| G | 16mm |
| s1 | 30.5mm |
| T | 52.5mm |
| Static load Cr | 23.2 kN |
| Dynamic load Cor | 35.1 kN |
| Fatigue load limit Pu | 0.98 kN |
| Limiting speed | 4000 rpm |
| Weight | 2.55 kg |
