SKU: HCP211
HCP211 Metric Cast Iron Two Bolt Pillow / Plummer Block Housing with 55mm Eccentric Collar Insert
HCP211 Metric Cast Iron Two Bolt Pillow / Plummer Block Housing with 55mm Eccentric Collar Insert
Regular price
CHF 56.76
ex VAT
Regular price
Sale price
CHF 56.76
ex VAT
In stock
Price Break
10+
CHF 50.52
19+
CHF 47.68
29+
CHF 47.11
39+
CHF 46.54
49+
CHF 45.98
74+
CHF 45.41
99+
CHF 42.57
199+
CHF 42.00
249+
CHF 41.43
499+
CHF 40.87
999+
CHF 39.73
Couldn't load pickup availability
Description
Description
HCP200 Series Normal Duty 2 Bolt Pillow Block Housings: These bearing units are supplied with a fully sealed bearing insert fitted in the cast iron housing. The bearing insert has an eccentric collar and grub screws to allow locking to the shaft once fitted. The inserts can be removed from the housings for future replacement as required.
Benefits: Can be re-lubricated, replaceable bearing insert, eccentric collar / grub screw fixing
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 55mm
- Style:
- HCP
- Bolt Hole Centres:
- 171mm
Technical
Technical
| d | 55mm |
|---|---|
| h | 63.5mm |
| e | 171mm |
| a | 219mm |
| b | 60mm |
| s1 | 20mm |
| s2 | 23mm |
| g | 23mm |
| w | 125mm |
| B1 | 71.4mm |
| n | 27.8mm |
| Bolt size | M16 |
| Bearing no | HC211 |
| Housing no | P211 |
| Weight | 3.5 kg |
