SKU: HCP211-32
HCP211-32 Imperial Cast Iron Two Bolt Pillow / Plummer Block Housing with 2 inch Eccentric Collar Insert
HCP211-32 Imperial Cast Iron Two Bolt Pillow / Plummer Block Housing with 2 inch Eccentric Collar Insert
Regular price
CHF 45.14
ex VAT
Regular price
Sale price
CHF 45.14
ex VAT
In stock
Price Break
10+
CHF 40.17
19+
CHF 37.92
29+
CHF 37.47
39+
CHF 37.01
49+
CHF 36.56
74+
CHF 36.11
99+
CHF 33.86
199+
CHF 33.40
249+
CHF 32.95
499+
CHF 32.50
999+
CHF 31.60
Couldn't load pickup availability
Description
Description
HCP200 Series Normal Duty 2 Bolt Pillow Block Housings: These bearing units are supplied with a fully sealed bearing insert fitted in the cast iron housing. The bearing insert has an eccentric collar and grub screws to allow locking to the shaft once fitted. The inserts can be removed from the housings for future replacement as required.
Benefits: Can be re-lubricated, replaceable bearing insert, eccentric collar / grub screw fixing
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 50.8mm = 2 inch
- Style:
- HCP
- Bolt Hole Centres:
- 171.05mm = 6.734 (6-47/64) inch
Technical
Technical
| d | 2 inch |
|---|---|
| h | 2-1/2 inch |
| e | 6-47/64 inch |
| a | 8-5/8 inch |
| b | 2-3/8 inch |
| s1 | 25/32 inch |
| s2 | 29/32 inch |
| g | 29/32 inch |
| w | 4-59/64 inch |
| B1 | 2.811 inch |
| n | 1.094 inch |
| Bolt size | 5/8 inch |
| Bearing no | HC211-32 |
| Housing no | P211 |
| Weight | 3.8 kg |
