SKU: HCP212
HCP212 Metric Cast Iron Two Bolt Pillow / Plummer Block Housing with 60mm Eccentric Collar Insert
HCP212 Metric Cast Iron Two Bolt Pillow / Plummer Block Housing with 60mm Eccentric Collar Insert
Regular price
CHF 75.06
ex VAT
Regular price
Sale price
CHF 75.06
ex VAT
In stock
Price Break
10+
CHF 66.80
19+
CHF 63.05
29+
CHF 62.30
39+
CHF 61.55
49+
CHF 60.80
74+
CHF 60.05
99+
CHF 56.30
199+
CHF 55.54
249+
CHF 54.79
499+
CHF 54.04
999+
CHF 52.54
Couldn't load pickup availability
Description
Description
HCP200 Series Normal Duty 2 Bolt Pillow Block Housings: These bearing units are supplied with a fully sealed bearing insert fitted in the cast iron housing. The bearing insert has an eccentric collar and grub screws to allow locking to the shaft once fitted. The inserts can be removed from the housings for future replacement as required.
Benefits: Can be re-lubricated, replaceable bearing insert, eccentric collar / grub screw fixing
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 60mm
- Style:
- HCP
- Bolt Hole Centres:
- 184mm
Technical
Technical
| d | 60mm |
|---|---|
| h | 69.8mm |
| e | 184mm |
| a | 241mm |
| b | 70mm |
| s1 | 20mm |
| s2 | 23mm |
| g | 25mm |
| w | 138mm |
| B1 | 77.8mm |
| n | 31mm |
| Bolt size | M16 |
| Bearing no | HC212 |
| Housing no | P212 |
| Weight | 4.76 kg |
